anicorn 3PCS DC 12V-36V Voltage Protection Module Digital Low Voltage Protector Disconnect Switch Over Discharge Protection Module Output 6-60V XH-M609

anicorn digital battery over-discharge protection switch is specially designed for 12-36V lithium and lead-acid battery. This is a low voltage protection module, not included any battery. When the battery voltage reaches the setting values, the module will disconnect load automatically to prevent the battery from over-discharging so as to prolong the battery lifetime.; Low voltage disconnect 12V
Main functions: over charge protection, over discharge protection function, short circuit protection function, over current protection function.; The low voltage cutoff
Supply Voltage: DC 12-36V,
Output Voltage: Equal to supply voltage,
Control Precision: 0.1V
Power: 1.5W; Instantaneous maximum current before circuit breaker trip: 20A.; anicorn low voltage disconnect Only suitable for a single battery, not for battery pack; Compatible with 12-36V lithium and lead acid battery; On-board momentary push button to set the low voltage disconnect parameter and 3 digit red LED display the parameter easy to operation. When the battery voltage reach the setting values, the module will disconnect load automatically to aviod the battery from over discharging to prolong the battery lifetime.
(Note: The relay does not contain a power cut-off switch, remember to cut off the power supply after disconnection, otherwise the module will continue to use the battery until the voltage is 0. )
