Portable Linux Android USB Multi SIM Card Reader With With PC/SC CCID Protocal DCR3516

Portable Linux Android USB Multi SIM Card Reader With With PC/SC CCID Protocal DCR3516 General Support standard card / SIM card / Micro SIM card / NANO SIM card Feature Ergonomic and cost-effective design software Compatible with identities SCR35xx card reader series Level 1 certified Compatible with all major ISO7816 standard smart cards on the market Application The reader is suitable for a variety of uses such as home banking, network security, tax, social security, secure login, electronic signature, corporate information security, email, encryption, membership cards, digital TV, mobile and telecom operators, e-coupons and games The application of high safety.

DCR3516 is a telecommunications industry operators must use the front of the application card reader, the use of convenience, a substantial provision of work efficiency Specification Interface Hi-Speed USB 2.0 (12 Mbps) Power source From USB Smart Card / PSAM Card (contact) T=0, T=1 protocol support Memory card support through SCM MCARD API Communication speed up to 600 kbps (PPS, Fl parameter) Frequency up to 8MHz (PPS, Dl parameter) Support ISO 7816 Class A and AB smart card 8 contacts - ISO 7816 location Service life Up to 100.000 times (friction type) Cable 1.5 m long with USB type A connector Optical Red LED Operating system Win dows® XP/Vista/7/8 (32&64Bit) Win dows® Server 2003/2008/2008 R2/2012 Win dows® CE 6.0, 7.0 Mac OS 10.5.

x, 10.6. x, 10.7. x, 10.8. x Linux 2.4. x, 2.6. x (32&64Bit) Android 2.3 above Size 68*47*13mm (L*W*H) Weight 78g API Software
