Gigabit PoE+ Injector 90W, 802.3af/at/bt Power Over Ethernet Metal PoE Adapter, 10/100/1000Mbps, Non-PoE to PoE Adapter, Plug & Play, Distance Up to 100 Meters (328 ft.)
- 2 Gigabit PortsThis PoE injector include 1× Gigabit Ethernet Input Port, and 1× Gigabit Ethernet Output port with PoE power. Max 1000Mbps with excellent data performance. PoE+ injector 48V/90W can Convert Non-PoE to PoE, you can easily have PoE enabled With no need to replace your existing non-PoE switch/device.
- 90W 802.3at/af/btThe PoE Port support IEEE802.3af(15.4W), IEEE802.3at(30W), IEEE802.3bt(90W), max output 90W, With 3 LED lights to display the power status, automatic detection of equipment and output required power, no forced power supply, no damage to the equipment.*Please note that passive 24V devices are not powered*.
- Plug and Play Easy to use, just plug in the power cord, the 2 ports connect to network devices and POE devices, no configuration required to work normally.
- Long Distance Transmit data and power over the single network cable up to 100 metres (328 feet), perfect for PoE devices that can be flexibly installed in a larger area.
- Widely UsedDesktop/Wall-Mount Me
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Previous page YuLinca engaged in the research and development, manufacturing, sales and service of ethernet network and comprehensive IT peripherals. YuLinca committed to provide high quality and cost-effective products, include POE injector, POE switch, 1G/ 2.5G /10G switch, Managed switch, etc. 1G/ 2.5G /10G Switch 1G/ 2.5G /10G poe injector Gigabit PoE Switch Industrail din rail switch RackMount PoE Switch Next page The PGN901 Gigabit PoE++ Injector fully complies with IEEE 802.3 af/at/bt PoE standards with up to 90W power supply. Plug and Play, flexible wall-mount Installation. It can easily expand your network to where there are no power lines, It is ideal for connecting IP Cameras, APs.
90W PoE Power Output Complies with IEEE 802.3 af/at/bt standards, supplies up to 90W, It auto detect the required power for PDs. Gigabit Ports Ensure Faster Connections Both the input and output port are gigabit speed, ensure faster and more reliable connections for all devides. Delivering power up to 100 meters (328ft. ), perfect for IP cameras or access point deployment in large areas. Plug and Play Plug & Play installation, no software setup or configuratio required, Just plug the Ethernet enabled device into the injector. Wall-mounting and desktop design Wall-mounting and desktop design provide flexible mounting options, It suitable for most installation scenarios.
Delivers power and data to PoE device from up to 100 meters (328 feet) over a single Ethernet cable. It is ideal for IP surveillance, digital signage and other PoE devices. Technical Parameter Model PGN901 Ports 1× 1Gbps/100Mbps/10Mbps RJ45 data-in port, 1× 1 Gbps/100 Mbps/10 Mbps RJ45 power+data-out port (Max. 90 W), 1× AC socket Standards and Protocols IEEE 802.3 (10Base-T) IEEE 802.3 u (100Base-TX) IEEE 802.3 ab (1000Base-TX) PoE Protocols IEEE 802.3 af, IEEE 802.3 at, IEEE 802.3 bt
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m), 100BASE-TX: UTP category 5, 5e cable (maximum 100 m), 1000BASE-T: UTP category 5, 5e, 6 cable (maximum 100 m)
Power Consumption Input: 100-240 V, 50/60 Hz, Output: Auto-determine the necessary power requirements (max. 90 W) LED Power / PoE Dimensions ( W x D x H ) 172*76*42mm Product Weight 0.6 kg Working
Environment Working Temperature: -0~40°C
Storage Temperature: -40~70°C
Working Humidity: 10%~90%, non-condensing
Storage Temperature: 5%~95%, non-condensing Package List PoE Injector 1 pcs, Power cord 1 pcs, User manual 1 pc The PGN901 Gigabit PoE++ Injector fully complies with IEEE 802.3 af/at/bt PoE standards with up to 90W power supply. Plug and Play, flexible wall-mount Installation. It can easily expand your network to where there are no power lines, It is ideal for connecting IP Cameras, APs. 90W PoE Power Output Complies with IEEE 802.3 af/at/bt standards, supplies up to 90W, It auto detect the required power for PDs. Gigabit Ports Ensure Faster Connections Both the input and output port are gigabit speed, ensure faster and more reliable connections for all devides. Delivering power up to 100 meters (328ft. ), perfect for IP cameras or access point deployment in large areas. Plug and Play Plug & Play installation, no software setup or configuratio required, Just plug the Ethernet enabled device into the injector. Wall-mounting and desktop design Wall-mounting and desktop design provide flexible mounting options, It suitable for most installation scenarios. Delivers power and data to PoE device from up to 100 meters (328 feet) over a single Ethernet cable.
It is ideal for IP surveillance, digital signage and other PoE devices. Technical Parameter Model PGN901 Ports 1× 1Gbps/100Mbps/10Mbps RJ45 data-in port, 1× 1 Gbps/100 Mbps/10 Mbps RJ45 power+data-out port (Max. 90 W), 1× AC socket Standards and Protocols IEEE 802.3 (10Base-T) IEEE 802.3 u (100Base-TX) IEEE 802.3 ab (1000Base-TX) PoE Protocols IEEE 802.3 af, IEEE 802.3 at, IEEE 802.3 bt
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m), 100BASE-TX: UTP category 5, 5e cable (maximum 100 m), 10
90W PoE Power Output Complies with IEEE 802.3 af/at/bt standards, supplies up to 90W, It auto detect the required power for PDs. Gigabit Ports Ensure Faster Connections Both the input and output port are gigabit speed, ensure faster and more reliable connections for all devides. Delivering power up to 100 meters (328ft. ), perfect for IP cameras or access point deployment in large areas. Plug and Play Plug & Play installation, no software setup or configuratio required, Just plug the Ethernet enabled device into the injector. Wall-mounting and desktop design Wall-mounting and desktop design provide flexible mounting options, It suitable for most installation scenarios.
Delivers power and data to PoE device from up to 100 meters (328 feet) over a single Ethernet cable. It is ideal for IP surveillance, digital signage and other PoE devices. Technical Parameter Model PGN901 Ports 1× 1Gbps/100Mbps/10Mbps RJ45 data-in port, 1× 1 Gbps/100 Mbps/10 Mbps RJ45 power+data-out port (Max. 90 W), 1× AC socket Standards and Protocols IEEE 802.3 (10Base-T) IEEE 802.3 u (100Base-TX) IEEE 802.3 ab (1000Base-TX) PoE Protocols IEEE 802.3 af, IEEE 802.3 at, IEEE 802.3 bt
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m), 100BASE-TX: UTP category 5, 5e cable (maximum 100 m), 1000BASE-T: UTP category 5, 5e, 6 cable (maximum 100 m)
Power Consumption Input: 100-240 V, 50/60 Hz, Output: Auto-determine the necessary power requirements (max. 90 W) LED Power / PoE Dimensions ( W x D x H ) 172*76*42mm Product Weight 0.6 kg Working
Environment Working Temperature: -0~40°C
Storage Temperature: -40~70°C
Working Humidity: 10%~90%, non-condensing
Storage Temperature: 5%~95%, non-condensing Package List PoE Injector 1 pcs, Power cord 1 pcs, User manual 1 pc The PGN901 Gigabit PoE++ Injector fully complies with IEEE 802.3 af/at/bt PoE standards with up to 90W power supply. Plug and Play, flexible wall-mount Installation. It can easily expand your network to where there are no power lines, It is ideal for connecting IP Cameras, APs. 90W PoE Power Output Complies with IEEE 802.3 af/at/bt standards, supplies up to 90W, It auto detect the required power for PDs. Gigabit Ports Ensure Faster Connections Both the input and output port are gigabit speed, ensure faster and more reliable connections for all devides. Delivering power up to 100 meters (328ft. ), perfect for IP cameras or access point deployment in large areas. Plug and Play Plug & Play installation, no software setup or configuratio required, Just plug the Ethernet enabled device into the injector. Wall-mounting and desktop design Wall-mounting and desktop design provide flexible mounting options, It suitable for most installation scenarios. Delivers power and data to PoE device from up to 100 meters (328 feet) over a single Ethernet cable.
It is ideal for IP surveillance, digital signage and other PoE devices. Technical Parameter Model PGN901 Ports 1× 1Gbps/100Mbps/10Mbps RJ45 data-in port, 1× 1 Gbps/100 Mbps/10 Mbps RJ45 power+data-out port (Max. 90 W), 1× AC socket Standards and Protocols IEEE 802.3 (10Base-T) IEEE 802.3 u (100Base-TX) IEEE 802.3 ab (1000Base-TX) PoE Protocols IEEE 802.3 af, IEEE 802.3 at, IEEE 802.3 bt
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m), 100BASE-TX: UTP category 5, 5e cable (maximum 100 m), 10
