1CH 2CH 8CH LAN Ethernet Relay Board Delay Network Switch TCP/UDP Controller Module WEB Server digital input 5V 12V 24V DC POWER

00 (UDP is not supported) CH1 pull 11 CH1 release 21 CH2 pull 12 CH2 release 22 CH3 pull 13 CH3 release 23 CH4 pull 14 CH4 release 24 CH5 pull 15 CH5 release 25 CH6 pull 16 CH6 release 26 CH7 pull 17 CH7 release 27 CH8 pull 18 CH8 release 28 Under TCP mode, the module after receiving the command byte, will return the latest status of each relay. The return value is a text string of eight characters, each character may be 0 or 1, on behalf of the relay releases or pull the state, such as the return value of 11 million represents CH1 and CH2 pull, the other channels are released state.

Delay parameters can be set in a controlled channel 1-65535 seconds later change the state, combined with the specific application can be implemented after the release delay is turned on or pull-off delay. Delay parameter is written after the command code continue to enter ": " and the delay in seconds, such
as: Current Status Command Code Description CH1 current state is release 11:30 CH1 pull, automatic release after 30 seconds The current state is pull 22:30 CH2 release, automatically pull after 30 seconds CH2 current state is release 22:30 or negative
