C2 Black C2BK, HTPC ITX Mini computer case in aluminum, support 3.5'' HDD, USB3.0, Home theater computer, Others C3 V4

C2 Black C2BK, HTPC ITX Mini computer case in aluminum, support 3.5 '' HDD, USB 3.0, Home theater computer, Others
C3 V4 Official Website: www.. com/en/products_24_2. html Overview C2 is introduced by in February 2014 with right angular design element ITX chassis. With the guarantee of good appearance, workmanship and quality, it is not an easy task to develop an aluminum ITX case with low price, but we believe that we make it with C2. For hardware support for C2, you will be surprised with its strong compatibility, it supports ATX PSU, 3.5 and 2.5 inch HDD, dual-slot full height display card, all kind of ITX motherboard, and even most of the MATX motherboard with sizes smaller than 245 × 215MM.
Specification Model: C2BK (Black), Dimension: 200 mm (W) x 270 mm (H) x 224 mm (D), Motherboard: ITX (170mm x 170mm) and Micro-ATX (245 x 215 MM)
CPU Cooler: the max height 80mm (not built-in)
Cooling System:
Bottom: 1 × 120 / 140mm fan (Not built-in)
Material: Top
cover: 1.5MM anodized aluminum alloy plate
HDD rack: 1.0MM anodized aluminum alloy
Other: 1.2MM anodized Aluminum alloy
Drive Bay: 1)170x170MM
motherboard installed:
(HDD: 2x 3.5, 2x 2.5, if 12 or 14cm fan is installed then HDD will be 1x 3.5, 1x 2.5 ), 2)245x215MM
motherboard installed:
(HDD: 1x 3.5 or 1x 2.5 )
Front I/O: USB 3.0 × 1, USB 2.0 × 1, Audio × 1, Mic × 1
VGA Card: Not looger than 220mm
Expansion Slot: 3
Power Supply: PSII (ATX) (not built-in), NET/Gross
Weight: 1.2KG / 1.7KG Design and Features
