Brand: BTF-LIGHTING
Gray level: 256
View angle: 120°
Input voltage: DC12V
FPCB Width: 12mm The color of
FPCB: White
Recommand power supply: DC12V10A 120W
Standard Reel Length: 16.4 ft/roll 5m/roll
Power: 0.1 - 0.4W /LED 6W-24W/m
Total: 30W-120W This is a variable value
Storage Temperature: -40? ~+50 °C
Operating Temperature: -25? ~ +50°C
Color temperature: Warm White 2700K-3000K
Color: RGBWW 4 in 1 RGB (red green blue) +
Warm White Led Qty: 60leds/m. 300RGB LEDs+300 Warm White LEDs Wave length (nm): Red, 620-625nm; Green, 520-525nm; Blue, 465-470nm
Luminous flux: Red 1.0 - 2.0 lumens
Green: 3.0 - 4.0 lumens
Blue: 1.0 - 2.0 lumens
White: 5.0 - 6.0 lumens
Waterproof level: IP30 non-waterproof
NOTE: PIN
Order: +12V-G-R-W-B (NOT RGBW+12V or +12V RGBW) When you light up 1 color (red or green or blue), each LED is 0.1W. If you light up 2 colors (red+green), each LED is 0.2W, when you light up 3 colors (red+green+blue), each LED is 0.3W, when you light up 4 colors (red+green+blue+warm white), each LED is 0.4W. It is not recommended to light up red+ blue+ green mixed white, so the voltage drop obviously Power adapter or controller is not included Features 4 in 1 4 colors(red, green, blue, white) mixed in 1 led. 60leds/m, 300 RGB leds + 300 pure Warm White. Two kinds of white Red+green+blue is mixed white. Warm white is pure white. Two kinds of white can be free to switch. Cuttable Every three leds can be cut off, led strip still working after cutting. Cut it to the length you just need. Colorful
