Product parameters and specifications:
Brand: BTF-LIGHTING
Gray level: 256
View angle: 120°
Input voltage: DC12V
FPCB Width: 12mm
LED strip width: 14mm (including the waterproof tube )
FPCB Color: White
Recommand power supply: DC12V10A 120W
Standard Reel Length: 16.4 ft/roll 5m/roll
Power: 0.1 - 0.4W /LED 6W-24W/m
Total: 30W-120W This is a variable value
Storage Temperature: -40~+50 °C
Operating Temperature: -25 ~ +50°C
Color temperature: Cool White 6000K-7000K
Color: RGBCW 4 in 1 RGB (red green blue) +Cool
White Led Qty: 60leds/m. 300RGB LEDs+300 Cool White LEDs Wave length (nm): Red, 620-625nm; Green, 520-525nm; Blue, 465-470nm
Luminous flux: Red 1.0 - 2.0 lumens
Green: 3.0 - 4.0 lumens
Blue: 1.0 - 2.0 lumens
White: 5.0 - 6.0 lumens
Waterproof level: IP67 Silicone Tube
Waterproof NOTE: PIN
Order: +12V-G-R-W-B (NOT RGBW+12V or +12V RGBW) When you light up 1 color (red or green or blue), each LED is 0.1W. If you light up 2 colors (red+green), each LED is 0.2W, when you light up 3 colors (red+green+blue), each LED is 0.3W, when you light up 4 colors (red+green+blue+cool white), each LED is 0.4W. It is not recommended to light up red+ blue+ green mixed white, so the voltage drop obviously Features 4 in 1 4 colors(red, green, blue, white) mixed in 1 LED. 60leds/m, 300 RGB + 300 pure Cool White. Two kinds of white Red+green+blue is mixed white. Cool White is pure white. Two kinds of white can be free to switch. Cuttable Every three leds can be cut off, led strip still working after cutting. Cut
