Ubiquiti UniFi Cloud Gateway Industrial (UCG-Industrial) (270W)

Ruggedized, fanless 10 GbE UniFi Cloud Gateway delivering 350W of total system power for high-density PoE deployments, with advanced routing capabilities and microSD storage for full UniFi application support.

SIM Slots Note: The onboard SIM slots are for Remote SIM integration with the UniFi 5G Max Outdoor (not for standalone cellular use). Additional support is planned via future software updates.

1. Form Factor: Wall-mounted / Compact desktop / Rack mount (accessory sold separately)
2. Coverage Area: 115 m² (1,250 ft²)
3. UniFi Application Suite: Network / Protect / Access / Talk / Connect
4. Managed UniFi Devices: 50+
5. Managed Cameras: (15) HD / (8) 2K / (5) 4K
6. Managed Access Hubs: 50
7. Simultaneous Users Connected: 500+

1. Max WAN Port Count: 5
2. Default WAN Ports: (1) 10G SFP+ / (1) 10 GbE RJ45 / (1) 2.5 GbE RJ45

1. Port Layout (2.5 GbE RJ45): 4 ports (2x PoE+++, 2x PoE+) (2.5G/1G/100M)
2. Port Layout (10 GbE RJ45): 1 port (PoE+++) (10G/5G/2.5G/1G/100M)
3. Port Layout (10G SFP+): 1 port (10G/1G)

1. IDS/IPS Throughput: 5 Gbps

1. Networking: Multi-WAN Load Balancing
2. Dynamic Routing: OSPF
3. Advanced QoS: Yes
4. Multicast DNS (mDNS): Yes
5. Advanced NAT: SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT
6. Integrated RADIUS Server: Yes
7. RADIUS over TLS (RadSec): Yes
8. Internet Failover: UniFi LTE Backup (additional)
9. Internet Quality and Outage Reporting: Yes
10. MAC Address Table Size: 4,000
11. Virtual Network Override: Yes

1. Integrated WiFi Standard: 802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7)
2. WiFi Throughput (5 GHz): 4.3 Gbps
3. WiFi Throughput (2.4 GHz): 688 Mbps
4. WiFi MIMO (5 GHz): 2x2 (DL/UL MU-MIMO)
5. WiFi MIMO (2.4 GHz): 2x2 (DL/UL MU-MIMO)
6. Antenna Gain (5 GHz): Stub 5 dBi / Terminal (Omni) 6 dBi
7. Antenna Gain (2.4 GHz): Stub 3 dBi / Terminal (Omni) 6 dBi
8. Max TX Power (5 GHz): 26 dBm
9. Max TX Power (2.4 GHz): 23 dBm

1. NVR Storage: Pre-installed 128 GB microSD for NVR
2. Expansion Slot: MicroSD Card

1. PoE Budget: DC input 270W / ATX power 75W
2. Max PoE per Port (PoE+): 30W
3. Max PoE per Port (PoE+++): 90W
4. PoE Voltage Range: 5057V
5. Max Power Consumption: 28W (excluding PoE output)

1. Power Method: (1) DC Input (350W PSU) / (1) ATX power (48V)
2. Power Supply: 54V DC 350W (adapter included) / ATX power (48V)
3. Supported Voltage Range: 100240V AC
4. Heat Dissipation: 85 BTU/hr (excluding PoE output)

1. Processor: Quad-core ARM Cortex-A73 2.2 GHz
2. System Memory: 3 GB

1. Management: Ethernet / Bluetooth
2. LEDs: Ethernet / SFP+ / System / MicroSD / SIM
3. Buttons: (1) Factory reset / (2) Handle release buttons
4. Application Requirements: Web Application / UniFi iOS v10.32.0+ / UniFi Android v10.35.0+
