BLE 5.0 Smart Bluetooth Scan Gateway Wireless WiFi Bridge for Smart Home IOT Indoor Location
- Maximum scan range: 30 meters in open field.
- Can send data to local or cloud server via RJ45 cable or WiFi.
- With the performance of Scanning 300pcs broadcasting in 1s.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Our Bluetooth gateway can scan the beacon, collect the beacons broadcasting information such as UUID, name, and RSSI, and then send the data packet to the local or cloud server via RJ45 cable or WiFi.
Bluetoothversion: BLE 5.0
WorkingFrequency: 2.402G ~ 2.483GH z
Antenna: Embedded antenna
MaxScanningRange: 30 m in open field
BluetoothChipset: nRF52832
MaxScanningNumber: 300 pieces broadcasting in 8 seconds
Averagepowerconsumption: 110mA, peak power consumption is 500mA (Using WIFI)
WorkingTemperature: -20ºC ~+65ºC
PowerSupply: 5V
USBchargingWireless: IEEE 802.11 b/g/n
Network: RJ45/WiFi
Networkprotocol: TCP/IP, DHCP
Bluetoothprotocols: LC, LM, L2CAP, ATT, GATT
Size: 106mm *106mm * 30mm
Authentication: Support Wifi security authentication Features Automatic scanning After being powered by the gateway and built a TCP connection with the server, the gateway will automatically scan the surrounding BLE device. And upload MAC address device name, broadcasting type, broadcasting content, and in time signal power to the server. Support various devices It can monitor the device conforms to the BLE standard. Low operating cost Bluetooth is applied to the worldwide open 2.4G band, so its operating cost is almost zero. Applications Device data collection Staff monitor in school, workshop, etc. Smart home, building automation Logistics Medical Exercise and fitness IoT
Bluetoothversion: BLE 5.0
WorkingFrequency: 2.402G ~ 2.483GH z
Antenna: Embedded antenna
MaxScanningRange: 30 m in open field
BluetoothChipset: nRF52832
MaxScanningNumber: 300 pieces broadcasting in 8 seconds
Averagepowerconsumption: 110mA, peak power consumption is 500mA (Using WIFI)
WorkingTemperature: -20ºC ~+65ºC
PowerSupply: 5V
USBchargingWireless: IEEE 802.11 b/g/n
Network: RJ45/WiFi
Networkprotocol: TCP/IP, DHCP
Bluetoothprotocols: LC, LM, L2CAP, ATT, GATT
Size: 106mm *106mm * 30mm
Authentication: Support Wifi security authentication Features Automatic scanning After being powered by the gateway and built a TCP connection with the server, the gateway will automatically scan the surrounding BLE device. And upload MAC address device name, broadcasting type, broadcasting content, and in time signal power to the server. Support various devices It can monitor the device conforms to the BLE standard. Low operating cost Bluetooth is applied to the worldwide open 2.4G band, so its operating cost is almost zero. Applications Device data collection Staff monitor in school, workshop, etc. Smart home, building automation Logistics Medical Exercise and fitness IoT
