Ubiquiti - ECS-48-PoE (2150W)

Enterprise Campus 48 PoE - ECS-48-PoE (2150W)
Enterprise-grade 48-port, Layer 3 Etherlighting PoE+++ switch with high-capacity 10 GbE RJ45 and 25G SFP28 connections for high availability system design.

Overview
Dimensions: 442.4 x 43.7 x 496 mm ( 17.4 x 1.7 x 19.5" )
Form Factor: 1U Rack Mount
Etherlighting: Yes
Redundancy: (2) Hot-Swappable PSUs, (4) Hot-Swappable Fans
Key Features
Ports: (16) 2.5 GbE RJ45, (32) 10 GbE RJ45 (All PoE+++), (4) 25G SFP28
Max PoE Output: Up to PoE+++ with 2, 150W shared mode
Switching Capacity: 920 Gbps
Total Non-Blocking Throughput: 460 Gbps
Layer 3: Yes (Supports Inter-VLAN Routing, Static Routing, DHCP Server)
Performance
Forwarding Rate: 684 Mpps
Supported VLA
Ns: 1, 000
MAC Address Table Size: 128, 000
L3 Table Size: 256, 000 IPv4 Routes
Layer 3 Features
DHCP Server (Local Networks)
Inter-VLAN Routing (Local Networks)
Static Routing (Local Networks)
Layer 2 Features
LACP Port Aggregation
STP & RSTP
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
IGMP Snooping
802.1X Control
MAC-Based ACLs & Device Isolation
DHCP Snooping & Guarding
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Rate Limiting
MAC Address Blocking
IP-Based ACLs & Network Isolation
MAC-Based Port Restriction
Port Isolation
Port Mirroring
Jumbo Frames
LLDP-MED
Voice VLAN
Loop Protection
Hardware
PoE Ports: 48 (PoE+++)
Max PoE Wattage per Port: 90W (PoE+++)
Max Power Consumption: 250W (Excluding PoE Output) - 2, 400W (Including PoE Output)
Power Method: (2) Universal input, 100-240V AC, 50/60 Hz
Power Input Method: (2) AC input, Hot-swappable power modules
Power Supply: (2) Hot-swappable AC/DC 1, 200W power modules
Supported Voltage Range: 100240V AC
Management: Ethernet, AR
Heat Dissipation (Excluding PoE Output): 853 BTU/hr
Weight: With
mounting brackets: 9.56 kg ( 21.1 lb) -
Without mounting brackets: 9.46 kg ( 20.9 lb)
Enclosure Material: SGCC steel
Supported Rack Depth: 482.6 mm (19") four-post racks, Posts depths ranging from 650 to 1, 000 mm ( 25.639. 4)
LCM Display: 1.3" touchscreen
ESD/EMP Protection: Air: ± 30kV, contact: ± 19kV
Ambient Operating Humidity: 10 to 90% noncondensing
Etherlighting: Ethernet, SFP28
LEDs: Ethernet, System
