HPE Aruba 6300L 48P 100M/1G/2.5G/5G CL8 2p SFP56 50G SFP28 Switch (S3L76A)

Ports:

-48x HPE Smart Rate 100M [5]/1G/2.5G/5G BaseT Class 6 PoE ports supporting up to 60W per port

-4x 1G/10G/25G/50G [4] SFP ports

Supports PoE standards IEEE 802.3af, 802.3at and 802.3bt (up to 60W)

-1x USB-C console port

-1x USB Type-A host port

-1x OOBM port

Latency:

1 Gbps: 4.24 s

10 Gbps: 1.50 s

25 Gbps: 2.91 s

50 Gbps: 3.49 s

Switching capacity: 780 Gbps

Stacking capabilities: Up to 10 members per stack.

Note: CX 6300L switches only stack with other CX 6300L switches

Throughput: 580 Mpps

Memory and processor: Quad Core Arm® Cortex® A72 @ 1.8GHz,

8 GB DDR4, 32 GB eMMC

Power supply:

2 fieldreplaceable, hotswappable power supply slots 1 minimum power supply required (ordered separately).

Supported PSUs: JL086A, JL087A and JL670A.

PoE capability: Maximum PoE power: 2880W

Fans: Switch has two fan tray slots and comes with one fan tray installed.

Minimum one fan tray required.

Fan trays are field replaceable and hotswappable. Each fan tray contains two fans.

Layer 2 only L switch does not support Layer 3 features in the F and M models

Power supplies sold separately for the HPE Aruba 6300L series switches.
