Cisco Catalyst 9200CX Network Essentials switch compact 8 ports managed rack-mountable
- Brand Cisco,
- Model C9200CX-8UXG-2X-E
- Product Description:Cisco Catalyst 9200CX - Network Essentials - switch - compact - 8 ports - managed - rack-mountable,
- Device Type: Switch - 8 ports - L3 - managed,
- Enclosure Type:Rack-mountable 1U,
- Subtype:Gigabit Ethernet,
- Ports: 4 x 10/100/1000 (UPOE) + 4 x 100/1000/2.5/5/10G (UPOE) + 2 x 10 Gigabit SFP+ (uplink),
- Power Over Ethernet (PoE): UPOE,
- PoE Budget:240 W,
- Performance:Switching capacity: 128 Gbps ¦ Forwarding rate: 95.23 Mpps ¦ Packet buffer size: 6 MB,
- Capacity:Virtual networks: 16 ¦ IPv4 routes: 14000 ¦ Direct IPv4 routes: 10000 ¦ Indirect IPv4 routes: 4000 ¦ IPv4 routing entries: 4000 ¦ IPv6 routing entries: 2000 ¦ Multicast scale: 1000 ¦ QoS scale entries: 1000 ¦ ACL scale entries: 1600 ¦ Flexible NetFlow entries: 16000 ¦ VLAN IDs: 4096 ¦ PVST instances: 128 ¦ STP Virtual Ports for PVST: 13000 ¦ STP Virtual Ports for MST: 13000,
- MAC Address Table Size: 32000 entries,
- Jumbo Frame Support: 9198 bytes,
Overview
Specs
Reviews
- Brand Cisco,
- Model C9200CX-8UXG-2X-E
- Product Description:Cisco Catalyst 9200CX - Network Essentials - switch - compact - 8 ports - managed - rack-mountable,
- Device Type: Switch - 8 ports - L3 - managed,
- Enclosure Type:Rack-mountable 1U,
- Subtype:Gigabit Ethernet,
- Ports: 4 x 10/100/1000 (UPOE) + 4 x 100/1000/2.5/5/10G (UPOE) + 2 x 10 Gigabit SFP+ (uplink),
- Power Over Ethernet (PoE): UPOE,
- PoE Budget:240 W,
- Performance:Switching capacity: 128 Gbps ¦ Forwarding rate: 95.23 Mpps ¦ Packet buffer size: 6 MB,
- Capacity:Virtual networks: 16 ¦ IPv4 routes: 14000 ¦ Direct IPv4 routes: 10000 ¦ Indirect IPv4 routes: 4000 ¦ IPv4 routing entries: 4000 ¦ IPv6 routing entries: 2000 ¦ Multicast scale: 1000 ¦ QoS scale entries: 1000 ¦ ACL scale entries: 1600 ¦ Flexible NetFlow entries: 16000 ¦ VLAN IDs: 4096 ¦ PVST instances: 128 ¦ STP Virtual Ports for PVST: 13000 ¦ STP Virtual Ports for MST: 13000,
- MAC Address Table Size: 32000 entries,
- Jumbo Frame Support: 9198 bytes,
- Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ae, IEEE 802.3at, IEEE 802.3bt,
- Power: AC 115/230 V (50/60 Hz),
- Dimensions (WxDxH): 10.6 in x 9.6 in x 1.7 in,
- Weight: 7.01 lbs,
- Manufacturer Warranty: Limited lifetime warranty,
- Device Type: Switch - 8 ports - L3 - managed,
- Enclosure Type: Rack-mountable 1U,
- Subtype: Gigabit Ethernet,
- Ports: 4 x 10/100/1000 (UPOE) + 4 x 100/1000/2.5/5/10G (UPOE) + 2 x 10 Gigabit SFP+ (uplink),
- Power Over Ethernet (PoE): UPOE,
- PoE Budget: 240 W,
- Performance:Switching capacity: 128 Gbps ¦ Forwarding rate: 95.23 Mpps ¦ Packet buffer size: 6 MB,
- RAM:4 GB,
- Flash Memory: 8 GB,
- Built-in Devices: RFID tag,
- Status Indicators: Power,
- Expansion / Connectivity,
- Interfaces: 4 x 10/100/1000 Base-T RJ-45 UPOE - 60 W ¦ 4 x 100/1000/2.5G/5G/10GBase-T RJ-45 UPOE - 60 W ¦ 2 x 10GBase-X SFP+ uplink ¦ 1 x USB 2.0 ¦ 1 x console (micro-USB),
- Expansion Slots: 1 (total) / 1 (free) x SD Memory Card,
- Power Device: Internal power supply,
- Power Provided: 315 Watt,
- Voltage Required:AC 115/230 V (50/60 Hz),
- Compliant Standards: Plug and Play, CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35,
- Software Included: Cisco IOS XE 17.9 Universal,
- Service & Support: Limited warranty - replacement - lifetime - response time: next business day ¦ Technical support - consulting - 90 days,
- Environmental Parameters
- Min Operating Temperature: 23 °F,
- Max Operating Temperature: 104 °F,
- Humidity Range Operating: 5 - 90% (non-condensing),
- Min Storage Temperature: -40 °F,
- Max Storage Temperature: 158 °F,
- Humidity Range Storage: 5 - 90% (non-condensing),
