Dell 7PXV8 Networking N3132PX-ON Managed Rack Mountable Switch

DELL 7PXV8 Emc Networking N3132px-on Switch 32
Ports Managed Rack-mountableKey Features: Device
Type: Switch 32
Ports L3 Managed StackableEnclosure Type: Rack-mountable
1uSubtype: Gigabit
EthernetPorts: 24 X 10/100/1000 (poe) + 8 X 100/1000/ 2.5 g/5g (poe) + 4 X 10 Gigabit Sfp+> Power Over
Ethernet (poe):
PoePerformance: Switching
Fabric Bandwidth: 328 Gbps, Forwarding
Performance: 428
MppsCapacity: Mac
Addresses: 32000, Aggregated
Links (dynamic): 144, Lag
Groups: 128, Queues
Per Port: 8, Vlans
Supported: 4094, Arp
Entries: 6144, Ndp
Entries: 400, Max
Acl Rules System-wide: 4096, Acl: 100, Maximum Acl Rules Per Interface (ipv4)
Ingress Rules: 3072, Maximum Acl Rules Per Interface (ipv4)
Egress Rules: 1024, Maximum Acl Rules Per Interface (ipv6)
Ingress Rules: 1021, Maximum Acl Rules Per Interface (ipv6)
Egress Rules: 512, Multicast
Entries (ipv4): 1536, Multicast
Entries (ipv6): 512, Ospf
Routes: 8160Mac
Address Table Size: 32000
EntriesRouting Protocol: Igmpv2, Igmp, Pim-sm, Pim-dm, Igmpv3, Mldv2, MldRemote
Management Protocol: Snmp 2, Rmon 1, Rmon 2, Snmp, Rmon 3, Rmon 9, Telnet, Http, Tftp, Ssh-2Encryption
Algorithm: Aes, Ssl, Tls 1.0A uthentication
Method: Radius, Tacacs+, LdapFeatures: Mdi/mdi-x Switch, Auto-negotiation, Port Mirroring, Ip Address Filtering, Access Control List (acl) Support, Quality Of Service (qos), Front To Back Airflow, Lldp Support, Remote Switch Port Analyzer (rspan), Management Information Base (mib), Dual Firmware Images, Redundant Fans, Mac And Ip-based Acls Support, Time-controlled
Acls Supportcompliant Standards: Ieee 802.2, Ieee 802.3, Ieee 802.3 u, Ieee 802.3 z, Ieee 802.1 d, Ieee 802.1 q, Ieee 802.3 ab, Ieee 802.1 p, Ieee 802.3 x, Ieee 802.3 ad (lacp), Ieee 802.1 w, Ieee 802.1 x, Ieee 802.3 ae, Ieee 802.3 ac, Ieee 802.1 s, Ieee 802.1 v, Ansi/tia-1057, Ieee 802.1 ab (lldp), Ieee 802.3 at, Ieee 802.3 az, Ieee
802.3 axRam: 2
GbFlash Memory: 512 MbExpansion /
Connectivity:
Interfaces: 24 X Gigabit Lan - Rj-45 - Poe8 X 5gbit Lan - Rj-45 - Poe4 X 10gbit Lan - Sfp+1 X 1000base-t - Rj-45 - Management1 X Usb -
Type APower: Power
Device: Internal Power Supply -
Hot-plugInstalled Qty: 1 (installed) / 2 (max)
Power Provided: 1100
WattCondition: Refurbished.
Availability: In Stock.
Our Warranty: 30 Days
