Dell N3048EP EMC Networking N3048EP-ON - 48 ports - switch

DELL Emc Networking N3048EP-ON - Switch - 48 Ports - Managed -
Rack-mountable: Key
Features: Device
Type: Switch - 48 Ports - L3 - Managed -
StackableEnclosure Type: Rack-mountable
1uSubtype: 10
Gigabit EthernetPorts: 48 X 10/100/1000 (poe+) + 2 X 10 Gigabit Sfp+ + 2
X Combo Gigabit SfpPerformance: Switching
Fabric Bandwidth: 260
Gbps ¦ Forwarding Performance: 193
Mpps ¦ Stacking Bandwidth: 21
GbpsCapacity: Ipv4
Routes (static): 1024 ¦ Ipv6
Routes (static): 1024 ¦ Ipv4
Routes (dynamic): 8160 ¦ Ipv6
Routes (dynamic): 4096 ¦ Maximum Member
Ports Per Lag: 8 ¦ Maximum Dynamic Ports Per Switch Stack: 144
¦ Lag Groups: 128
¦ Ospf Routes: 8160
¦ Rip Routes: 512 ¦ Ecmp Next Hops Per Route: 4
¦ Ecmp Groups: 64
¦ Vlan Routing Interfaces: 128
¦ Vlans Supported: 4094
¦ Multicast Entries (ipv4): 1536
¦ Multicast Entries (ipv6): 512
¦ Arp Entries: 6144
¦ Ndp Entries: 400
¦ Acl: 100
¦ Maximum Rules Per Acl: 1023
¦ Max Acl Rules System-wide: 4096 ¦ Maximum Acl Rules Per Interface (ipv4)
Egress Rules: 1024 ¦ Maximum Acl Rules Per Interface (ipv4)
Ingress Rules: 3072 ¦ Maximum Acl Rules Per Interface (ipv6)
Egress Rules: 512 ¦ Maximum Acl Rules Per Interface (ipv6)
Ingress Rules: 1021 ¦ Maximum Vlan Interfaces With Acls Applied: 24Mac
Address Table Size: 32k
EntriesRouting Protocol: Ospf, Rip-1, Rip-2, Igmpv2, Igmp, Vrrp, Ospfv2, Pim-sm, Pim-dm, Igmpv3, Ospfv3, Mldv2, MldRemote
Management Protocol: Snmp 1, Snmp 2, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Telnet, Snmp 3, Http, Tftp, Ssh-2Encryption
Algorithm: Md5, Aes, Ssl, TlsAuthentication
Method: Radius, Tacacs+, Secure Shell V.
2 (ssh2) Features: Flow Control, Mdi/mdi-x Switch, Auto-negotiation, Arp Support, Vlan Support, Port Mirroring, Diffserv Support, Weighted Round Robin (wrr) Queuing, Broadcast Storm Control, Ipv6 Support, Rapid Spanning Tree Protocol (rstp) Support, Multiple Spanning Tree Protocol (mstp) Support, Access Control List (acl) Support, Quality Of Service (qos), Stp Root Guard, Ipv4 Support, Lldp Support, Link Aggregation Control Protocol (lacp), Energy Efficient Ethernet, Management Information Base (mib), Dynamic Vlan Support (gvrp), Dual Firmware Images, Network Access Control (nac), Neighbor Discovery Protocol (ndp), Tagged Vlan, Redundant Fans, Protocol-based
Vlans SupportCompliant Standards: Ieee 802.2, Ieee 802.3, Ieee 802.3 u, Ieee 802.3 z, Ieee 802.1 d, Ieee 802.1 q, Ieee 802.3 ab, Ieee 802.1 p, Ieee 802.3 x, Ieee 802.3 ad (lacp), Ieee 802.1 w, Ieee 802.1 x, Ieee 802.3 ae, Ieee 802.3 ac, Ieee 802.1 s, Ieee 802.1 v, Ansi/tia-1057, Ieee 802.1 ag, Ieee 802.1 ab (lldp), Ieee 802.3 at, Ieee 802.3 az, Ieee
802.3 axRam: 2
GbFlash Memory: 1 GbExpansion /
Connectivity:
Interfaces: 48 X Gigabit Lan Rj-45 36 Ports (poe+) / 12 Ports (poe) - 30.8 W ¦ 2 X 10gbit Lan Sfp+ ¦ 2 X Gigabit Lan Rj-45/sfp ¦ 1 X Serial (rs-232) Rj-45 Management ¦ 1 X Usb Type A ¦ 2 X
Network Stack DevicePower: Power
Device: Internal Power Supply -
Hot-plugInstalled Qty: 2 (installed) / 2 (max)
Power Redundancy: OptionalPower
Provided: 1100
WattCondition:
RefurbishedAvailability: In
StockOur Warranty: 30 Days
