HPE Aruba 2930F 24G (JL259A) - Managed 24-Port Rack-Mountable Switch with 4 SFP Ports
- Type: Managed L3 stackable
- Ports: 24 x 10/100/1000 + 4 x Gigabit SFP
- Performance: 41.7 Mpps throughput, 56 Gbps capacity
- Capacity: Jumbo frame size 9220, IPv4 routing 10,000 entries, IPv6 routing 5,000 entries
- Management: SNMP, RMON, Telnet, SSH
- Security: MD5, SSL, RADIUS, TACACS+
- Features: VLAN, IGMP snooping, QoS, DHCP server, LACP, LLDP, OpenFlow
- Standards: IEEE 802.1D, 802.1Q, 802.3af, 802.1x, 802.1s
- Processor: 1 x ARM Cortex-A9 @ 1.016 GHz
- Memory: 1 GB DDR3 SDRAM
- Power: Internal supply, AC 120/230 V, 29.3 Watt consumption, 80 PLUS Silver
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Device Type: Managed L3 stackable switch
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 4 x Gigabit SFP (uplink)
Performance:
Throughput: 41.7 Mpps
Switching capacity: 56 Gbps
Latency (1 Gbps): 3.8 µs
Jumbo frame size: 9220
Capacity:
IPv4 routing table entries: 10, 000
IPv6 routing table entries: 5, 000
MAC Address Table Size: 32K entries
Routing Protocol:
OSPF, RIP, RIP-1, RIP-2, BGP, IGMP, static IP routing, static IPv4 routing, static IPv6 routing, RIPng, MLD, CIDR
Remote Management Protocol:
SNMP 1, SNMP 2, RMON 1, SNMP, Telnet, SNMP 3, SNMP 2c, SSH, SSH-2, CLI, XRMON
Encryption Algorithm:
MD5, SSL
Authentication Method:
RADIUS, PAP, CHAP, TACACS, TACACS+
Features:
Flow control, full duplex capability, DHCP support, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, DiffServ support, IPv6 support, SNTP support, sFlow, STP support, MSTP support, ACL support, QoS, Jumbo Frames support, DHCP server, STP Root Guard, Uni-Directional Link Detection (UDLD), LLDP support, LACP, Management Information Base (MIB), MAC address lockout, dynamic ARP protection, DHCP protection, Dynamic VLAN Support (GVRP), Multiple VLAN Registration Protocol (MVRP), NDP, CoS, ToS, OpenFlow support, CPU protection, ICMP, ICMP Router Discovery Protocol (IRDP), VXLAN, Management Information Base (MIB) II
Compliant Standards:
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1 p, IEEE 802.3 af, IEEE 802.3 x, IEEE 802.3 ad, IEEE 802.1 w, IEEE 802.1 x, IEEE 802.1 s, IEEE 802.1 ad, IEEE 802.1 v, IEEE 802.1 ab, IEEE 802.3 at, IEEE 802.3 az, IEEE 802.1AX
Processor:
1 x ARM Cortex-A9 @ 1.016 GHz
Memory:
RAM: 1 GB DDR3 SDRAM
Flash Memory: 4 GB
Expansion / Connectivity:
Interfaces: 24 x 1000Base-T RJ-45, 4 x Gigabit LAN SFP, 1 x serial (console)
Expansion Slots: 1 (total) / 1 (free) x expansion slot
Installed Modules Qty (Max): 0 (installed) / 4 (max)
Power:
Power Device: Internal power supply
Installed Qty: 1
Voltage Required: AC 120/230 V
Power Consumption Operational: 29.3 Watt
80 PLUS Certification: 80 PLUS Silver
Enclosure Type: Rack-mountable 1U
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 4 x Gigabit SFP (uplink)
Performance:
Throughput: 41.7 Mpps
Switching capacity: 56 Gbps
Latency (1 Gbps): 3.8 µs
Jumbo frame size: 9220
Capacity:
IPv4 routing table entries: 10, 000
IPv6 routing table entries: 5, 000
MAC Address Table Size: 32K entries
Routing Protocol:
OSPF, RIP, RIP-1, RIP-2, BGP, IGMP, static IP routing, static IPv4 routing, static IPv6 routing, RIPng, MLD, CIDR
Remote Management Protocol:
SNMP 1, SNMP 2, RMON 1, SNMP, Telnet, SNMP 3, SNMP 2c, SSH, SSH-2, CLI, XRMON
Encryption Algorithm:
MD5, SSL
Authentication Method:
RADIUS, PAP, CHAP, TACACS, TACACS+
Features:
Flow control, full duplex capability, DHCP support, BOOTP support, ARP support, VLAN support, IGMP snooping, Syslog support, DiffServ support, IPv6 support, SNTP support, sFlow, STP support, MSTP support, ACL support, QoS, Jumbo Frames support, DHCP server, STP Root Guard, Uni-Directional Link Detection (UDLD), LLDP support, LACP, Management Information Base (MIB), MAC address lockout, dynamic ARP protection, DHCP protection, Dynamic VLAN Support (GVRP), Multiple VLAN Registration Protocol (MVRP), NDP, CoS, ToS, OpenFlow support, CPU protection, ICMP, ICMP Router Discovery Protocol (IRDP), VXLAN, Management Information Base (MIB) II
Compliant Standards:
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1 p, IEEE 802.3 af, IEEE 802.3 x, IEEE 802.3 ad, IEEE 802.1 w, IEEE 802.1 x, IEEE 802.1 s, IEEE 802.1 ad, IEEE 802.1 v, IEEE 802.1 ab, IEEE 802.3 at, IEEE 802.3 az, IEEE 802.1AX
Processor:
1 x ARM Cortex-A9 @ 1.016 GHz
Memory:
RAM: 1 GB DDR3 SDRAM
Flash Memory: 4 GB
Expansion / Connectivity:
Interfaces: 24 x 1000Base-T RJ-45, 4 x Gigabit LAN SFP, 1 x serial (console)
Expansion Slots: 1 (total) / 1 (free) x expansion slot
Installed Modules Qty (Max): 0 (installed) / 4 (max)
Power:
Power Device: Internal power supply
Installed Qty: 1
Voltage Required: AC 120/230 V
Power Consumption Operational: 29.3 Watt
80 PLUS Certification: 80 PLUS Silver
