HPE FlexNetwork A7506 Switch Chassis 0235A1NX (JD239C)

The HPE FlexNetwork 7500 Switch Series comprises modular, multi-layer chassis switches that meet the evolving needs of integrated services networks. The switches can be deployed in multiple network layer, and wiring closet edge. They offer 40GbE connectivity and cost-effective, wire your mission-critical data and high-s environments, including the enterprise LAN core, aggregation speed 10GbE ports to safeguard the throughput and bandwidth needed for communications. A passive backplane, support for load sharing, and redundant management and fabrics help the switch series provide high availability. Moreover, these switches deliver wire-speed Layer 2 and Layer 3 routing services for the most demand hardware based IPv4 and IPv6 support.

HPE FlexNetwork 7506
Switch Chassis (JD239C): Modules, Power Supplies Sold Separately
Included Accessories: 1 HP 7506 Spare Fan Assembly (JD214A)
I/O Ports and Slots: 6 I/O module slots Supports a maximum of 288 PoE/PoE+ Gigabit Ethernet ports or 288 autosensing 10/100/1000 ports or 288 1/10GbE ports or 288 10GbE ports or 28 40GbE ports, or a combination Additional
Ports and Slots: 2 switch fabric slots
Power Supplies: 2 power supply slots 1 minimum power supply required (ordered separately)
Fan Tray:
Includes: 1 x JD214A 1 fan tray slot
Physical Characteristics: Dimensions 17.17 (w) x 16.54 (d) x 22.64 (h) in ( 43.6 x 42.0 x 57.5 cm) (13U height) Weight 207 lb ( 93.9 kg) shipping weight
Mounting and Enclosure: Mounts in an EIA-standard 19 in. rack or other equipment cabinet (hardware included); Horizontal surface mounting only
Reliability: Availability 99.999 %
Environment: Operating temperature 32°F to 113°F (0°C to 45°C) Operating relative humidity 10% to 95%, noncondensing Non-operating/Storage temperature -40°F to 158°F (-40°C to 70°C) Non-operating/Storage relative humidity 5% to 95%, noncondensing
Acoustic Low-speed fan: 53.6 dB, High-speed
fan: 57.7 dB
Electrical Characteristics: Frequency 50/60 Hz Achieved Miercom Certified Green Award Description The H3C S7506E (HPE 7606) is Certified Green in the 2009 Miercom Green Switches Industry Assessment Voltage 100 - 120 / 200 - 240 VAC, rated -48 to -60 VDC, rated (depending on power supply chosen)
