Switch 10gbps Rj45 10g Web Managed 5 Ports Ethernet Switch
- Hubs
- 5-Port 10G Web Managed Ethernet Switch This 5-Port 10G RJ45 Ethernet Switch delivers high-speed connectivity with full 10Gbps transmission rate, ideal for demanding network environments requiring fast data transfer and low latency.
- High Switch Capacity & Efficient Power Supply With a switch capacity of 120G and DC 12V 1A power requirement this switch efficiently handles high-bandwidth traffic while using an external AC100-240V 50/60Hz power supply for universal compatibility.
- Compact Design & Easy Installation Measuring 200 x 118 x 44mm this compact switch fits seamlessly into any rack or workspace. Its 5 x 10G RJ45 ports provide ample connectivity for high-speed network setups.
+
+
Overview
Specs
Reviews
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
Hubs
Specification
5* 10G RJ45 ports
Port Standard
IEEE802.3 (Ethernet)
IEEE802.3u (Fast Ethernet)
IEEE802.3ab (Gigabit Ethernet)
IEEE 802.3bz (5G Ethernet)
IEEE 802.3z (Gigabit Ethernet)
IEEE 802.3ae (10G Ethernet)
IEEE802.3x (Flow Control)
Bandwidth
100Gbps
Packet Forwarding Rate
74.4Mpps
Packet Buffer
12Mbit
MAC Address Table
16K
Power Supply
AC 100-240V 50/60Hz
DC 12V 2A
Mainboard Power Consumption
20.89W
Structure Information
Product Dimensions :200*118*44mm
Packaging Dimensions : 245*190*60mm
Product Net Weight:0.67kg
Product Gross Weight:0.9kg
Description
Specification
Package Information
Carton Dimensions :520*320*400mm
Packing Quantity: 20PCS
Packing Weight: 18.9kg
Package Contents
Switch 1pcs,ac adapter 1pcs,manual 1pcs,certificate of qualification 1pcs
Fan Quantity
1
Installation
Desktop
Surge Protection
Port Surge : Common mode 4KV, differential mode 2KV;
Electrostatic ESD: Air 8KV, Contact 6KV
Operating Temperature
0~40°C
Storage Temperature
-40 °C to 70 °C
Humidity
10%~90%,non condensing
Storage Humidity
5%~95%,non condensing
PWR
On: Powered on
Off: Powered off
SYS
On: The system is normal
Flashing: System startup in progress
1-5
Green Led On: 10G Link normal
Yellow Led On: 100/1000Mbps/2.5Gbps Link normal
Off: Link blocked
Support
Port Rate-limit
Support
VLAN
Access/Trunk/Hybrid
VLAN Tunnel (Q-in-Q Tunnel)
VLAN range 1-4094, maximum active VLAN is 4K
MAC Address
Filtering MAC Address
Static MAC address
Description
Specification
Spanning Tree Protocol
STP/RSTP
BPDU Filter
BPDU Guard
Edge Port
Multicast
IGMP Snooping
Router Port
Static IGMP Join
IGMP V1/V2
QoS
Traffic classification, Supporting SP and WRR scheduling
Port Priority
802.1P Priority
IP DSCP Priority
Priority Remarking
Supports up to 8 queues per port
ERPS
Main Ring
Services
Access Protocol
HTTP
Session Timeout
Security
DHCP Snooping
Diagnostics
Copper Test
Support
Ping
Support
Equipment Management
Manager Acces
HTTP
SNMP
Manager IP
Static Address
Manager VLAN
DNS
DHCP Client
Description
Specification
SNMP
V2C
Community
Trap Host
SNMP MIB
RFC 1213 MIB-II
RFC 1643 Ethernet MIB
RFC 2863 Interface MIB
User Management
Support
Firmware Management
Firmware upgrade
Configuration Management
Upload/Backup Configuration
Save
Support
Restart
Support
Factory Defaults
Support
Standard Compliance
IEEE 802.3x flow control and back pressure
IEEE 802.3ad port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN tagging
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP v1
RFC 2236 IGMP v2
RFC 3376 IGMP v3
Details Images
==========
High-concerned chemical :
communication mode : Full-Duplex & Half-Duplex
switch capacity : 120G
transmission rate : Other
model number : SST-WTG5ETG
function : LACP, QoS, SNMP, Stackable, VLAN Support
ports : Other
private mold : Yes
products status : Stock
Product Name : 5-Port 10G Web Managed Ethernet Switch
Interface : 5* 10G RJ45 ports
Power Supply : External power supply:AC100-240V 50/60Hz
Working Voltage : DC 12V 1A
Dimensions (W x D x H) : 200*118*44mm
Operating Temperature : -10 ~ 50
Specification
5* 10G RJ45 ports
Port Standard
IEEE802.3 (Ethernet)
IEEE802.3u (Fast Ethernet)
IEEE802.3ab (Gigabit Ethernet)
IEEE 802.3bz (5G Ethernet)
IEEE 802.3z (Gigabit Ethernet)
IEEE 802.3ae (10G Ethernet)
IEEE802.3x (Flow Control)
Bandwidth
100Gbps
Packet Forwarding Rate
74.4Mpps
Packet Buffer
12Mbit
MAC Address Table
16K
Power Supply
AC 100-240V 50/60Hz
DC 12V 2A
Mainboard Power Consumption
20.89W
Structure Information
Product Dimensions :200*118*44mm
Packaging Dimensions : 245*190*60mm
Product Net Weight:0.67kg
Product Gross Weight:0.9kg
Description
Specification
Package Information
Carton Dimensions :520*320*400mm
Packing Quantity: 20PCS
Packing Weight: 18.9kg
Package Contents
Switch 1pcs,ac adapter 1pcs,manual 1pcs,certificate of qualification 1pcs
Fan Quantity
1
Installation
Desktop
Surge Protection
Port Surge : Common mode 4KV, differential mode 2KV;
Electrostatic ESD: Air 8KV, Contact 6KV
Operating Temperature
0~40°C
Storage Temperature
-40 °C to 70 °C
Humidity
10%~90%,non condensing
Storage Humidity
5%~95%,non condensing
PWR
On: Powered on
Off: Powered off
SYS
On: The system is normal
Flashing: System startup in progress
1-5
Green Led On: 10G Link normal
Yellow Led On: 100/1000Mbps/2.5Gbps Link normal
Off: Link blocked
Support
Port Rate-limit
Support
VLAN
Access/Trunk/Hybrid
VLAN Tunnel (Q-in-Q Tunnel)
VLAN range 1-4094, maximum active VLAN is 4K
MAC Address
Filtering MAC Address
Static MAC address
Description
Specification
Spanning Tree Protocol
STP/RSTP
BPDU Filter
BPDU Guard
Edge Port
Multicast
IGMP Snooping
Router Port
Static IGMP Join
IGMP V1/V2
QoS
Traffic classification, Supporting SP and WRR scheduling
Port Priority
802.1P Priority
IP DSCP Priority
Priority Remarking
Supports up to 8 queues per port
ERPS
Main Ring
Services
Access Protocol
HTTP
Session Timeout
Security
DHCP Snooping
Diagnostics
Copper Test
Support
Ping
Support
Equipment Management
Manager Acces
HTTP
SNMP
Manager IP
Static Address
Manager VLAN
DNS
DHCP Client
Description
Specification
SNMP
V2C
Community
Trap Host
SNMP MIB
RFC 1213 MIB-II
RFC 1643 Ethernet MIB
RFC 2863 Interface MIB
User Management
Support
Firmware Management
Firmware upgrade
Configuration Management
Upload/Backup Configuration
Save
Support
Restart
Support
Factory Defaults
Support
Standard Compliance
IEEE 802.3x flow control and back pressure
IEEE 802.3ad port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN tagging
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP v1
RFC 2236 IGMP v2
RFC 3376 IGMP v3
Details Images
==========
High-concerned chemical :
communication mode : Full-Duplex & Half-Duplex
switch capacity : 120G
transmission rate : Other
model number : SST-WTG5ETG
function : LACP, QoS, SNMP, Stackable, VLAN Support
ports : Other
private mold : Yes
products status : Stock
Product Name : 5-Port 10G Web Managed Ethernet Switch
Interface : 5* 10G RJ45 ports
Power Supply : External power supply:AC100-240V 50/60Hz
Working Voltage : DC 12V 1A
Dimensions (W x D x H) : 200*118*44mm
Operating Temperature : -10 ~ 50
