26-Port Gigabit Uplink PoE Switch 24*10/100Mbps 2*10/100/1000M Uplink RJ45 Ports Support IEEE802.3af/at PoE Standard Smart PoE Switch
- Innovative FunctionThe smart 26port POE switch has 10/100M access, Gigabit uplink.This POE switch can support non-blocking wire-speed forwarding. Support full-duplex based on IEEE802.3x and half-duplex based on Backpressure. Provides 24*10/100M PoE ports and 2*10/100/1000M RJ45 ports for flexible networking and meets the networking requirements of various scenarios.
- 26Port POE + SwitchThe smart switch has 24*10/100M PoE ports and 2*10/100/1000M uplink RJ45 ports. Port 1-24can support IEEE802.3af/at PoE standard.Single-port PoE power up to 30W . As a PoE power supply device, it can automatically detect and recognize the power receiving equipment that meets the standard and supply power through the network cable.
- Smart PoE Power SupplyThe smart 26port POE switch comply with IEEE 802.3af/at PoE standard, without damaging non-PoE devices. 24*10/100Base-TX RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios. Priority
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Model:ONV-H1024PL
Interface Characteristics
Fixed Port:
24*10/100Base-TX PoE ports (Data/Power)
2*10/100/1000Base-T uplink RJ45 ports (Data)
Ethernet Port:
Port 1-16/ 1-24 support 10/100Base-TX and port 17-18/ 25-26 support 10/100/1000Base-T auto-sensing, full/ half duplex MDI/ MDI-X self-adaption
Functional Switch:
Port 9-16/ 17-24 can support 10M/250 meters transmission when the functional switch is on 250m.
Note: When the switch status changes, the PoE switch must be restarted for the function switch to take effect.
Twisted Pair Transmission:
10BASE-T: Cat3,4,5 UTP (250 meter)
100BASE-TX: Cat5 or later UTP (100 meter)
1000BASE-T: Cat5e or later UTP(100 meter)
Chip Parameter
Network Protocol:
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T
IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x
Forwarding Mode: Store and Forward (Full Wire Speed)
Switching Capacity: 14.8Gbps (Non-blocking)
Forwarding: 6.55Mpps
Rate@64byte
MAC: 16K
Buffer Memory: 4M
Jumbo Frame: 9.6K
LED Indicator: Power: PWR (Green), Network : Link (Yellow), PoE: PoE (Green)
PoE & Power Supply
PoE Port: Port 1 to 24
Power Supply Pin: 1/2(+) 3/6(-)
Max Power Per Port: 30W, IEEE 802.3 af/at
Total PWR / Input Voltage: 250W/ (AC100-240V)
Power Consumption: Standby <20W, Full load <250W
Power Supply: Built-in switching power supply, AC100~240V 50-60Hz, 4.1A
