XGSPON ONU Stick SFP+ with MAC Optical Transceiver,Version 8311,Compatible Ubiquiti Mikro-TIK Netgate TP Link 10G Switches and Routers SMF 9.953G-TX/9.953G-RX,1270 nm-TX/1577 nm-RX
- This product is applicable to the Compatible Ubiquiti, MikroTik ,Netgate,TP Link, 10G Switches and Routers,8311 Firmware Version (Supports Web management), Chipset: MaxLinear PRX126 (SMF, 9.953G-TX/9.953G-RX,1270 nm-TX/1577 nm-RX, 20km, SC/APC, DDM)
- Firmware Compatibility: Supports 8311 community firmware.Streamlined device configuration with one-click web setup! Access the interface at 192.168.11.1 using username root (no password required).
- SFP package with SC /APC receptacle High power 1270 nm DML DFB LD and high sensitivity 1577 nm APD,Support 20km transmission distance with SMF,CML-compatible data input/output interface.
- Hot-pluggable capability Low power dissipation < 3W,Case temperature range: -40 °C to 85 °C Low EMI and excellent ESD protection
- Support of GPON/XGS-PON/NGPON2 standards256 GEM/XGEM ports, 64 T-CONTs or 16 LLIDs
- Allows configuration of parameters such as PON serial number (ONT ID), Vendor ID, Equipment ID, Logical ONU ID, Logical password, and MAC add
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
XGSPON ONU Stick SFP+ with MAC Transceiver,8311 Firmware Version (Supports Web management), Chipset: MaxLinear PRX126 (SMF, 9.953G-TX/9.953G-RX,1270 nm-TX/1577 nm-RX, 20km, SC/APC, DDM)
The XGSPON ONU stick with MAC module is designed for 10G passive optical network systems.
The STICK optical module can fully meet the requirements of the carrier-grade FTTB\ FTTH\ FTTO device.
It can be hot-swapped into the SFP+ slot of the Layer 2 Ethernet switch.
The whole machine can be used as an ONT or even an MDU to connect the entire device to the XGSPON optical network directly. The central office OLT only needs to register the XGSPON ONU STICK optical module as if it were a typical optical CAT.
The communication device can complete the access switch from the original P2P.
Custom XGSPON ONU Stick SFP+
Firmware Compatibility: Supports 8311 community firmware.
Hardware Specs: High-performance design with 1 GB RAM for seamless operation.
Customization Support
Allows configuration of the following parameters:
PON serial number (ONT ID)
Vendor ID
Equipment ID
Logical ONU ID
Logical password
MAC address
Product Features
Compatible: Ubiquiti Series 10G Switches
Form :XGSPON ONU Stick SFP+
Brand name:FiberMall
Single fiber bi-directional data links symmetric TX 9.953 Gb/s / RX 9.953 Gb/s with MAC function
SFP package with SC /APC receptacle
Single 3.3 V power supply
Hot-pluggable capability
High power 1270 nm DML DFB LD and high sensitivity 1577 nm APD
Support 20km transmission distance with SMF
CML-compatible data input/output interface
Low power dissipation <3W
Low EMI and excellent ESD protection
Digital diagnostic monitor interface
RoHS-6 compliance
Case temperature range: -40 °C to 85 °C
Support of GPON/XGS-PON/NGPON2 standards
256 GEM/XGEM ports, 64 T-CONTs or 16 LLIDs
Carrier Grade QoS Engine
Advanced loopback and diagnostic capabilities
Supports Synchronous Ethernet (SyncE)
Applications
Residential home gateway
Network switch/router, VDSL MDU, and G.fast DPU
Mobile backhaulStandard
Complies with ITU-T G.987.2
Complies with ITU-T G.9807.1, G.9807.2
ITU-T G.988 OMCI L2 MAC Bridge (Up to 64 L2 bridges)
G.8275/Y.1369/IEEE 1588v2
IEEE 802.1ag and ITU-T Y.1731 Ethernet OAM delay & loss measurement hardware support
The XGSPON ONU stick with MAC module is designed for 10G passive optical network systems.
The STICK optical module can fully meet the requirements of the carrier-grade FTTB\ FTTH\ FTTO device.
It can be hot-swapped into the SFP+ slot of the Layer 2 Ethernet switch.
The whole machine can be used as an ONT or even an MDU to connect the entire device to the XGSPON optical network directly. The central office OLT only needs to register the XGSPON ONU STICK optical module as if it were a typical optical CAT.
The communication device can complete the access switch from the original P2P.
Custom XGSPON ONU Stick SFP+
Firmware Compatibility: Supports 8311 community firmware.
Hardware Specs: High-performance design with 1 GB RAM for seamless operation.
Customization Support
Allows configuration of the following parameters:
PON serial number (ONT ID)
Vendor ID
Equipment ID
Logical ONU ID
Logical password
MAC address
Product Features
Compatible: Ubiquiti Series 10G Switches
Form :XGSPON ONU Stick SFP+
Brand name:FiberMall
Single fiber bi-directional data links symmetric TX 9.953 Gb/s / RX 9.953 Gb/s with MAC function
SFP package with SC /APC receptacle
Single 3.3 V power supply
Hot-pluggable capability
High power 1270 nm DML DFB LD and high sensitivity 1577 nm APD
Support 20km transmission distance with SMF
CML-compatible data input/output interface
Low power dissipation <3W
Low EMI and excellent ESD protection
Digital diagnostic monitor interface
RoHS-6 compliance
Case temperature range: -40 °C to 85 °C
Support of GPON/XGS-PON/NGPON2 standards
256 GEM/XGEM ports, 64 T-CONTs or 16 LLIDs
Carrier Grade QoS Engine
Advanced loopback and diagnostic capabilities
Supports Synchronous Ethernet (SyncE)
Applications
Residential home gateway
Network switch/router, VDSL MDU, and G.fast DPU
Mobile backhaulStandard
Complies with ITU-T G.987.2
Complies with ITU-T G.9807.1, G.9807.2
ITU-T G.988 OMCI L2 MAC Bridge (Up to 64 L2 bridges)
G.8275/Y.1369/IEEE 1588v2
IEEE 802.1ag and ITU-T Y.1731 Ethernet OAM delay & loss measurement hardware support
