Consumption: Self-consumption<15W, PoE output 185W max Downlink ports: 1~8 ports: 10/100/1000Base-T 30W PoE RJ45(IEEE802.3af/at) Reset key: Short press restart, >5s press recovery to default Cable and distance: Use cat5e/6, 100m max."
Standard: IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3z, IEEE802.3ad, IEEE802.3az, IEEE802.1q, IEEE802.1p, IEEE802.1s, IEEE802.1d, IEEE802.1w, IEEE802.1x, IEEE802.1ad, IEEE802.1ab
Switch fabric: 20Gbps Though put: 14.88Mpps Buffer: 1M MAC address table: 8K Indicator: Power: 1 *red ; Downlink 1~8: On RJ45 green LEDs indicate Link/Act, yellow LEDs indicate PoE Uplink9, 10: On RJ45 green LEDs indicate Link/Act
Protection: Surge: 6KV, standard: IEC61000-4-5 ESD: 6KV: contact 8KV: air, standard:IEC61000-4-2 SPD: AC lightning arrester, 385v AC@20KA , 2p, - 40 ~ 70°C, lower incoming line, dxh06-fcs / 2r40 Working temperature: -20°C to 70°C Storage temperature: -40°C to 85°C Humidity: 0 to 95%(No condensation)
