GOTOTOP Gigabit Switch, 8 Port Fiber Optic Ethernet Converter
- IEEE802.3Z/AB Protocol, 10/100/1000M Adaptive, Single Mode Dual Fiber, Aluminum Alloy Housing, Full Duplex Signal Conversion
- IEEE802.3Z/AB Protocol: Supports 1000Base-SX/LX standard, full-duplex and half-duplex working modes for stable data transmission over fiber optic networks.
- Adaptive 10/100/1000M Conversion: Optical converter with adaptive electrical interface, automatically negotiates speed between 10Mbps, 100Mbps, and 1000Mbps for seamless integration.
- Single Mode Dual Fiber SC Interface: Duplex SC fiber ports with TX and RX interfaces, supports single-mode fiber (8.3/125, 9/125m) for long-distance signal conversion up to 1.25Gbps.
- Aluminum Alloy Housing: Durable metal enclosure ensures heat dissipation and structural integrity, suitable for industrial network cabinets or server room environments.
- Auto MDI/MDIX on RJ45: Integrated CAT5/CAT6 twisted pair ports with automatic straight/crossover line detection, eliminating manual cable configuration errors during setup.
+
+
Overview
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Specification:
Item Type: Gigabit Switch
Material: Aluminum Alloy
Standard Protocol: IEEE802.3Z/AB 1000Base-T/SX/LX
Transmission Rate: Electrical Interface: 10/100/1000Mbps; Optical Fiber Interface: 1.25Gbps
Operating Mode: Full-Duplex Mode or Half-Duplex Mode
Power Parameters: 5VDC
Ambient Temperature: 0-60
Relative Humidity: 5%-90%
TP Line: 5E, CAT6
Transmission Fiber: Multi-Mode: 50/125, 62.5/125um; Single-Mode:: 8.3/125, 8.7/125, 9/125 or 10/125m
How to Use:
1.Interface
R.J45 interface: The transmission medium adopts CAT5 and CAT 6 twisted pair cables. It is recommended to use highquality RJ45 and wellmade jumpers, which have the function of automatically identifying straight and crossover cables.
Optical fiber interface: SC optical fiber interface is duplex type, including TX and RX two interfaces. When two sets of optical converters are connected or connected to a switch through optical fiber interfaces, the optical fibers are in a crossedconnected state, that is, "TXRX" and "RXTX".
2. Connection
Connect network equipment (workstation, hub or switch)
Connect to the RJ45 socket of the optical converter through twisted pair CAT5. Connect the multimode/singlemode fiber to the SC/ST/LC fiber interface of the optical module. Turn on the power. The corresponding LED light is on to indicate that the connection is correct.
packing list:
1 x Gigabit Switch
1 x User Manual
Item Type: Gigabit Switch
Material: Aluminum Alloy
Standard Protocol: IEEE802.3Z/AB 1000Base-T/SX/LX
Transmission Rate: Electrical Interface: 10/100/1000Mbps; Optical Fiber Interface: 1.25Gbps
Operating Mode: Full-Duplex Mode or Half-Duplex Mode
Power Parameters: 5VDC
Ambient Temperature: 0-60
Relative Humidity: 5%-90%
TP Line: 5E, CAT6
Transmission Fiber: Multi-Mode: 50/125, 62.5/125um; Single-Mode:: 8.3/125, 8.7/125, 9/125 or 10/125m
How to Use:
1.Interface
R.J45 interface: The transmission medium adopts CAT5 and CAT 6 twisted pair cables. It is recommended to use highquality RJ45 and wellmade jumpers, which have the function of automatically identifying straight and crossover cables.
Optical fiber interface: SC optical fiber interface is duplex type, including TX and RX two interfaces. When two sets of optical converters are connected or connected to a switch through optical fiber interfaces, the optical fibers are in a crossedconnected state, that is, "TXRX" and "RXTX".
2. Connection
Connect network equipment (workstation, hub or switch)
Connect to the RJ45 socket of the optical converter through twisted pair CAT5. Connect the multimode/singlemode fiber to the SC/ST/LC fiber interface of the optical module. Turn on the power. The corresponding LED light is on to indicate that the connection is correct.
packing list:
1 x Gigabit Switch
1 x User Manual
