Yoidesu 5 Port PoE Switch 4 PoE Ports 250 Meters Outdoor IP55

Be the first to review this product...

4 PoE Ports, 1 Uplink, 250m Transfer, IP55 Water Resistance, VLAN Isolation, for Outdoor Security Cameras
[250m Long Distance] Extend PoE power and data transmission up to 250m / 820.21ft at 10Mbps, exceeding the standard 100m / 328.08ft range available at 100Mbps. This long range PoE switch is designed for outdoor monitoring layouts where cameras or other powered devices are positioned far from the network connection, helping simplify cabling across extended installation areas.
[4 PoE Ports and 45W Budget] Equipped with 4x 10/100Mbps PoE ports and 1x 10/100Mbps uplink port, this PoE network switch supports IEEE 802.3af/at standards and a total PoE power budget of 45W. Each PoE port supports up to 30W, providing a practical way to connect and power compatible security cameras, access points, and other network devices through Ethernet cables.
[VLAN Port Isolation] Activate VLAN isolation mode using the physical DIP switch without requiring software configuration. In this mode, the

Overview

Specs

Reviews

Any questions? Ask Celeste^SM will help you find out quickly.

Try me now

Specification:
Item Type: 5 Port Gigabit PoE Switch
Ports: 4x10/100Mbps PoE ports + 1x10/100Mbps uplink port
Total Ports: 5 ports
Power Budget: Total PoE budget 45W (Maximum 30W per port, supports IEEE 802.3af/at standards)
Transfer Rate: 100Mbps
Switching Backplane Bandwidth: 1Gbps
Transfer Distance: Up to 250m / 820.21ft (at 10Mbps) / standard 100m / 328.08ft (at 100Mbps)
Management Features: Supports VLAN port isolation (with physical DIP switch)
Power Supply: Wide voltage input (terminal block power supply, power plug not included)
Waterproofing Level: IP55 outdoor waterproofing
Operating Temperature: -20°C to 60°C
Installation Method: Wall mounted, pole mounted
Power Interface: Terminal block (live, neutral, ground, refer to the wiring diagram in the manual)

How to Use:
Take out and use

PackageList:
1 x 5 Port Gigabit PoE Switch
1 x Instruction Manual
1 x Green Terminal Block
2 x White Nylon Cable Ties
4 x Screws
4 x Expansion Plugs
