Gigabit Network Switch 24 Port Network adapter 10/100/1000Mbps VLAN Network switch 1000M switch

Features:

Model:TXE168

Products:24 ports Fast ethernet switch

Dimension:440*220*45mm

Standard and protocols:IEEE 802i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p

Interface:24 10/100/1000Mbps RJ45 Ports, Auto Negotiation/Auto MDI/MDIX

Forwarding mode :Store-and-Forward

Power supply AC power:100-240VAC, 50/60Hz

LED :Power, 1000Mbps, Link/Act

Fanless:Yes

802.1p/DSCP QoS::Yes

Network media:10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000BASE-T:

UTP category 5, 5e or above cable (maximum 100m)

Performance :

Switching Capacity 48Gb.

Packet Forwarding Rate 35.7Mpps.

MAC Address Table 8K.

Jumbo Frame 10KB.

Maximum Power Consumption 12.05W (220V/50Hz).

Certifications:CE, FCC, RoHS

Environment

Operating Temperature 0°C~40°C(32°F~104°F).

Storage Temperature -40°C~70°C(-40°F~158°F).

Operating Humidity 10%~90%RH non-condensing.

Storage Humidity 5%~90%RH non-condensing.

Package Included:

1 x 24-Port Gigabit switch
