Digitus ASSMANN Gigabit Active 802.3at PoE Midspan 4-Port Switch for Desktop, Laptop, IP Camera, Printer with RJ45, PoE Interface, Plastic Case

The effective distance is 100 meters over Cat5e/Cat6 cables. It is small in size but high performance

- Provides 52Vdc, 0.58A power for remote PDs over 2 pairs output
- Supports both 10/100 Base-T and Gigabit device
- Works with a wide input voltage of 100-240 VAC, 50 or 60 Hz.
- Easily merge of power and data cables into a single cable
- Each output port has output current limited, short-circuit protection, complete Powered Device (PD) detection and classification
- The Injector can be used independent of operating system

DN-95132 is an indoor rated active PoE midspan Injector specially designed for complex backhaul and networking applications. It provides 52Vdc, 0.58A power for remote PDs over 2 pairs output. It supports both 10/100 Base-T and Gigabit device. It works for 30W PoE PDs, such as wireless APs, WLAN routers, Network cameras, IP Phones, Microwave Radio and other power Ethernet terminals. It fully complies to IEEE802.3af/at PoE standard. Enclosed in an IP40 fire retardant plastic case. Enclosed in an IP40 fire retardant plastic case. It works with a wide input voltage of 100-240 VAC, 50 or 60 Hz. It has detection chip inside, which will detect and classify PD before powering it. It will not provide power until a standard-compliant PD is detected.
Ports & interfaces
-Ethernet LAN (RJ-45) ports: 2

Weight & dimensions

-Width: 107.3 mm
-Depth: 56 mm
-Height: 34 mm
-Weight: 146.8 g

Power

-AC adapter input voltage: 100 - 240 V
-AC adapter frequency: 50/60 Hz
-Input current: 1 A
-Output current: 0.58 A
-Total Power over Ethernet (PoE) budget: 30 W
-DC output voltage: 52 V

Operational conditions

-Operating temperature (T-T): 0 - 40 °C
-Operating relative humidity (H-H): 20 - 80%
-Storage temperature (T-T): -20 - 70 °C
-Operating altitude: 0 - 2000 m

Network
