MILWAUKEE VALVE 1509Y 2" Swing Y Check Valve, 1509Y Series, 2 in, Sweat x

The MILWAUKEE VALVE 1509Y is a 2 in. swing Y check valve with a bronze body and sweat x sweat connections. It is a one-way valve with a swing check mechanism and Y-style body for reverse-flow control in general-purpose piping systems for compatible chemical, natural gas, steam, and water applications. This valve supports horizontal or vertical mounting and features a full-flow design with a 0.5 psi cracking pressure.

Key Features:

• Valve type: Swing Y check valve with Y-pattern body and swing mechanism
• Body, seat, seal, and check mechanism material: Bronze
• Connection size: 2 in. on both sides
• Connection type: Sweat x sweat; solder connection
• Flow capacity: 131 gpm
• Cv: 92
• Pressure ratings: 300 psi maximum operating pressure; 300 psi at 150 degrees F maximum water pressure; 150 psi WSP maximum steam pressure
• Temperature range: -20 degrees F to 425 degrees F
• Mounting orientation: Horizontal or vertical
• Overall dimensions: 6.38 in. length x 5 1/4 in. height x 2 3/4 in. width
• Standard: MSS SP-80, Type 3
• Valve series: 1509Y
