Honeywell MK7580 Genesis 7580g Hands-Free Barcode Scanner, 1D/PDF/2D, RS232-TTL/USB/KBW, IBM 46xx RS485 via cable, USB Kit - MK7580-30B38-02-A
- The Genesis 7580g is the first presentation area-imaging scanner engineered to decode all standard 1D, PDF and 2D barcodes
- Its revolutionary imaging technology is housed in an elegant, yet durable design
- Powered by Adaptus Imaging Technology 6.0, the 7580g scanner packs breakthrough performance into a versatile form factor
- Excels at scanning coupons and mobile tickets directly from the screen of a mobile device
- Improves document management by capturing and storing electronic images, including coupons, personal checks, signatures and damaged packages
- Increases efficiency by simultaneously deactivating EAS tags and decoding barcodes from up to 17 cm (7 in) away
- Includes USB Cable
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Honeywell Genesis 7580g -- Area-Imaging Scanner
Honeywell's GenesisTM 7580g, the world's first presentation areaimaging scanner engineered to decode all standard 1D, PDF and 2D codes, provides enhanced productivity and revolutionary imaging technology in an elegant, yet durable design.
Powered by Adaptus® Imaging Technology 6.0, the Genesis 7580g is redefining industry standards for imaging solutions. Breakthrough performance and a versatile form factor make this product suitable for environments ranging from manufacturing to healthcare to retail POS.
Aggressive reading of bar codes on highly reflective surfaces, such as mobile phone screens, eliminates the need to purchase additional specialty hardware.
Patented CodeGate® technology along with an activation button support menu-scanning and other targeted-scanning applications.
Automatic cable detection and configuration simplifies migration to a new interface by eliminating the need to scan programming bar codes.
Three additional patented technologies augment the Genesis 7580g's unmatched feature set:
Shielded LEDs minimize the intense flashing common among other area imagers.
CodeSelectTM allows the Genesis 7580g to capture up to 15 bar codes in a single flash and output data in any predetermined order. TotalFreedom® expands scanner functionality by allowing decoding and formatting plug-ins to be loaded directly onto the Genesis 7580g, enabling enterprises to rapidly support proprietary or newly-developed symbologies.
Specifications
Mechanical
Dimensions (LxWxH): 80 mm x 83 mm x 150 mm
Weight: 340 g (12 oz)
Electrical
Input Voltage: 5.5 VDC ± 0.25 V
Operating System: 2.0 W (400 mA @ 5 V)
Standby Power: 0.5 W (100 mA @ 5 V)
Host System Interfaces: USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Auxiliary Ports: EAS with interlock (EAS model)
Environmental
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Humidity: 0% to 95% relative humidity, non-condensing
Drop: Designed to withstand 1.5 m (5´) drops
Environmental Sealing: Sealed to resist airborne particulate contaminants
Light Levels: 100,000 Lux
Scan Performance
Scan Pattern: Area Image (832 x 504 pixel array)
Motion Tolerance: 200 cm/s (78 in/s) for 13 mil UPC at optimal focus
Scan Angle: Horizontal: 46°; Vertical: 28°
Print Contrast: 20% minimum reflectance difference
Pitch, Skew: 70°, 75°
Decode Capability: Reads standard 1D, PDF, 2D, Postal and OCR symbologies
*Note: Decode capabilities dependent on kit configuration
WPAN: Bluetooth® Class II (10 m) v2.0 Enhanced Data Rate (EDR) with on-board antenna. BQB certified
Honeywell's GenesisTM 7580g, the world's first presentation areaimaging scanner engineered to decode all standard 1D, PDF and 2D codes, provides enhanced productivity and revolutionary imaging technology in an elegant, yet durable design.
Powered by Adaptus® Imaging Technology 6.0, the Genesis 7580g is redefining industry standards for imaging solutions. Breakthrough performance and a versatile form factor make this product suitable for environments ranging from manufacturing to healthcare to retail POS.
Aggressive reading of bar codes on highly reflective surfaces, such as mobile phone screens, eliminates the need to purchase additional specialty hardware.
Patented CodeGate® technology along with an activation button support menu-scanning and other targeted-scanning applications.
Automatic cable detection and configuration simplifies migration to a new interface by eliminating the need to scan programming bar codes.
Three additional patented technologies augment the Genesis 7580g's unmatched feature set:
Shielded LEDs minimize the intense flashing common among other area imagers.
CodeSelectTM allows the Genesis 7580g to capture up to 15 bar codes in a single flash and output data in any predetermined order. TotalFreedom® expands scanner functionality by allowing decoding and formatting plug-ins to be loaded directly onto the Genesis 7580g, enabling enterprises to rapidly support proprietary or newly-developed symbologies.
Specifications
Mechanical
Dimensions (LxWxH): 80 mm x 83 mm x 150 mm
Weight: 340 g (12 oz)
Electrical
Input Voltage: 5.5 VDC ± 0.25 V
Operating System: 2.0 W (400 mA @ 5 V)
Standby Power: 0.5 W (100 mA @ 5 V)
Host System Interfaces: USB, RS232, Keyboard Wedge, IBM 46xx (RS485)
Auxiliary Ports: EAS with interlock (EAS model)
Environmental
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature -40°C to 60°C (-40°F to 140°F)
Humidity: 0% to 95% relative humidity, non-condensing
Drop: Designed to withstand 1.5 m (5´) drops
Environmental Sealing: Sealed to resist airborne particulate contaminants
Light Levels: 100,000 Lux
Scan Performance
Scan Pattern: Area Image (832 x 504 pixel array)
Motion Tolerance: 200 cm/s (78 in/s) for 13 mil UPC at optimal focus
Scan Angle: Horizontal: 46°; Vertical: 28°
Print Contrast: 20% minimum reflectance difference
Pitch, Skew: 70°, 75°
Decode Capability: Reads standard 1D, PDF, 2D, Postal and OCR symbologies
*Note: Decode capabilities dependent on kit configuration
WPAN: Bluetooth® Class II (10 m) v2.0 Enhanced Data Rate (EDR) with on-board antenna. BQB certified
