CWWK N5105 Soft Routing Six Network Port i226 Network Card DDR4 Dual Memory/M.2 NVMe Solid State /4 USB/RS232 Serial Port (Barebone)
- Intel 11th generation Jasper Lake low-power quad core processor
- 6 INTEL 1226-V 2.5G network cards,1 M.2 NVMe (PCle3.0 x1) slot size 2280,Dual SO-DIMM DDR4 dual memory sockets, supporting 3200MHZ
- 1 HDM12.0 interface supports 4K 4096x2160@60Hz ),1 DP1.4a HD display interface supports (4096 × 2160@60Hz )
- Passive cooling without fan, zero noise, low power consumption TDP only 10W
- 1 SATA3.0 interface, supporting 2.5/3.5 inch (external) high-capacity hard disk,Built in USB GPIO TPM CPU-FAN FPANEL COM pin
- 4G/WiF communication module with full minicycle slot supporting USB signal
- CustomizableIf you need to customize the LOGO on the panel, please contact us and provide the source file for free laser laser engraving (PS: laser-engraved machines do not support return or exchange)
+
+
Overview
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
CPUIntel Celeron Jasper Lake N5105
Storage: 1 X M.2 NVME (PCIE3.0 x1) 1 X SATA3.0
Display: 1X HDMI2.0 1X DP1.4 (supported 4K@60Hz
USB:2*USB3.0/2*USB2.0
BIOS: AMI EFI BIOS call auto start, GPIO, watchdog, PXE
Memory: 2 X SO-DIMM DDR4 2933MHz compatible 2400/2266/3200MHz maximum 32 grams per strip
Graphics card: Intel UHD graphics (4 times more than J4125 integrated graphics card)
Network card: 6 X Intel i226-V (2.5G network card)
Heat dissipation: no fan, pure copper conductive aluminum shell passive heat dissipation
Power consumption: 10W
Power supply: DC12V-3A 100-24oV 50/60Hz (5.5 * 2.5 connector)
Chassis: aluminum alloy
Extension interface: SIM-COM GPIO USB TPM CPU-FAN pin
Expandable: small PCI-E supports 4G, WiFi, Bluetooth (to be customized)
Size: 155 mm wide × 125.3 mm (D) X 52.5 mm (H)
Color: iron grey/black
Installation mode: desktop type, wall mounted type (contact customer service to purchase additional wall mounted parts)
Working environment: - 0 ~470 Relative humidity 5% - 85%
Storage: 1 X M.2 NVME (PCIE3.0 x1) 1 X SATA3.0
Display: 1X HDMI2.0 1X DP1.4 (supported 4K@60Hz
USB:2*USB3.0/2*USB2.0
BIOS: AMI EFI BIOS call auto start, GPIO, watchdog, PXE
Memory: 2 X SO-DIMM DDR4 2933MHz compatible 2400/2266/3200MHz maximum 32 grams per strip
Graphics card: Intel UHD graphics (4 times more than J4125 integrated graphics card)
Network card: 6 X Intel i226-V (2.5G network card)
Heat dissipation: no fan, pure copper conductive aluminum shell passive heat dissipation
Power consumption: 10W
Power supply: DC12V-3A 100-24oV 50/60Hz (5.5 * 2.5 connector)
Chassis: aluminum alloy
Extension interface: SIM-COM GPIO USB TPM CPU-FAN pin
Expandable: small PCI-E supports 4G, WiFi, Bluetooth (to be customized)
Size: 155 mm wide × 125.3 mm (D) X 52.5 mm (H)
Color: iron grey/black
Installation mode: desktop type, wall mounted type (contact customer service to purchase additional wall mounted parts)
Working environment: - 0 ~470 Relative humidity 5% - 85%
