M.2 A+E Key to 2.5G Ethernet Adapter - NIC with Intel I226V, 100/1000/2500 Mbps RJ45 Stable Connection Cable Length 20cm, Compatible with OpenWRT | Windows | Linux | Server | PC | SBC (A+E with Screw)

Product description COMPARED M. 2 A+E Key 2.5G NIC Add to Cart M. 2 A+E Key 2.5G NIC Add to Cart M. 2 A+E Key 2.5G NIC Add to Cart M. 2 B+M Key 2.5G NIC Add to Cart Customer Reviews 3.8 out of 5 stars 21 4.3 out of 5 stars 14 4.0 out of 5 stars 1 4.6 out of 5 stars 3 Price $ 24.89 $24. 89 $ 25.39 $25. 39 $ 25.39 $25. 39 $ 24.89 $24. 89 Bus type M. 2 A+E Key M. 2 A+E Key M.

2 A+E Key M. 2 B+M Key Chipset I226V I226V I226V I226V Transmission Rate 2.5G /1000/100Mbps 2.5G /1000/100Mbps 2.5G /1000/100Mbps 2.5G /1000/100Mbps Interface 1x RJ45 Copper Cable 1x RJ45 Copper Cable 1x RJ45 Copper Cable 1x RJ45 Copper Cable Compatible Devices PC \ SBC \ Server \ Router PC \ SBC \ Server \ Router PC \ SBC \ Server \ Router PC \ SBC \ Server \ Router With screws no 1x M2*3 screw 1x M2*3 screw no Overview The M. 2 A+E \ B+M KEY I226 2.5G Ethernet Server Network Interface Card utilizes the high-performance I226-V Ethernet controller.

The I226-V controller features a Base-T copper network interface, providing a compact single-port integrated multi-gigabit ( 2.5G )-MDI (copper) standard IEEE 802.3 Ethernet interface for 2500BASE-T, 1000BASE-T, 100BASE-TX, and 10BASE-TE connections. The M. 2 A+E \ B+M KEY I226 2.5G Ethernet Server Network Interface Card is designed for: any mobile device, desktop, workstation, value server, or industrial design with stringent space constraints. Mainstream distributions based on kernel 5.10 and above offer native compatibility, eliminating the need for manual driver compilation and enabling plug-and-play functionality:
Enterprise-grade: RHEL 8.910, SLES 15 SP7;
Common desktop/industrial control systems: Ubuntu 20.04 LTS, Ubuntu 22.04 LTS, Debian 11;
Compatibility: Fully supports common embedded Linux systems used in industrial control computers, meeting the needs of industrial automation and edge computing scenarios.
Note: This M. 2 A+E key 2.5G Ethernet card is specifically designed for standard A+E slots. Some older small form factor desktops or motherboards may restrict the PCIe/power functions of the A+E WiFi slot, resulting in limited or no network connectivity. Before purchasing, please confirm your motherboard supports installing non-WiFi modules in the A+E slot to avoid affecting your usage.

Specifications

Compliant with PCI Express Specification Revision 3.1 ( 5.0 GT/s) MDI (Copper) Standard IEEE 802.3 Ethernet Interface, 2.5 Gb/s Compliant with Single-Port 2.5G bE RJ45 Port (Copper Cable) Compliant with MDI standard IEEE 802.3 Ethernet interface for 2500BASE-T, 1000BASE-T, 100BASE-TX, and 10BASE-TE applications (IEEE 802.3 bZ, IEEE 802.3 ab, IEEE 802.3 u, and IEEE 802.3 ), IEEE 802.3 auto-negotiation Supports IEEE 802.3 x and IEEE 802.3 z flow control with software-configurable RX threshold and TX pause frames Auto-crossover detection (MDI/MDI-X), IEEE 1588 protocol and 802.1AS implementation Supports Time-Sensitive Networking (TSN) functionality Supports LAN Wake-up for IEEE 802.3 az Energy Efficient Ethernet (EEE) Supports TCP/UDP, IPv4 Checksum Offload (Rx/Tx), Transmission Segment Offload (TSO) (IPv4, IPv6) Supports packets up to 9.5KB jumbo frames Technical

Specifications

Applicable Networks 2.5G Server Network Card Main Controller I226-V Chipset Bus Type M.

2 A+E \ B+M KEY Media Interface 1x RJ45 Copper Cable Transmission Rate 2.5G /1000/100Mbps Network Topology 2500BASE-T, 1000BASE-T, 100BASE-TX, 10BASE-TE; IEEE 802.3 b, IEEE 802.3, IEEE 802.3 x, IEEE 1588, IEEE 802.3 az; Energy Efficient Ethernet (EEE) Management Features IPMI delivery via SMBus or NC-SI, iSCSI boot, Wake-on-LAN (WoL), PXE remote boot, VLAN filtering Operating System Windows 10 32/64-bit, Windows 10 v1809 32/64-bit or later Product Certifications FCC, CE, ROHS Operating Temperature 0~55°C (32~131°F) Storage Temperature -40~70°C (-40~158°F) Storage Humidity 90% non-condensing relative humidity at 35°C Why is there no response when connecting to the M. 2 E slot? What's in the package Does it come with screws? Where can I find Linux drivers? See More
