Honeywell 1990ISR-3USB-A Ultra-Rugged Area-Imaging Scanner USB KIT TETHERED ULTRA RUGGEDINDUSTRIAL scanner 1D PDF417 2D SR FOCUS WITH VIBRATION RED barcode scanner 1990ISR3
- Honeywell Honeywell 1990iSR Heavy-Duty Handheld QR Code Scanner Overview
- The 1990iSR is an ultra-rugged imager that reads barcode symbols quickly and accurately, maximizing operational efficiency. Its nature lowers the total cost of ownership. Extreme scanning performance also enables fast scanning of damaged and low-quality barcodes. The new generation of Granit XP scanners further expands functionality and redefines the ultra-rugged scanner.
- Honeywell Honeywell 1990iSR Heavy Industrial Grade Handheld QR Code Scanner Features
- super sturdy
- It can be used in various harsh environments: including drops from a height of 3 meters at -20 to 50°C, and 7,000 rolls from a height of 1 meter. IP67 encapsulation level.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Honeywell Honeywell 1990iSR Heavy Industrial Grade Handheld QR Code Scanner Physical Parameters Mechanical parameters Dimensions (LxWxH) 192 mm x 76 mm x 100 mm Weight 320 g ( 11.3 oz) User Indicator LEDs for good decoding, buzzer (adjustable tone and volume), vibration (adjustable) Electrical parameters Input Voltage 4.0 VDC to 5.5 VDC Operating Power 2.35 W (470 mA @ 5 VDC) Standby Power 0.5 W (100 mA @ 5 VDC) System interface USB, keyboard port, RS-232 TTL Environmental parameters Operating Temperature -30°C to 50°C (-22°F to 122°F) Storage Temperature -40°C to 70°C (-40°F to 158°F) Humidity Up to 95% relative humidity, non-condensing
Drop: 2
m ( 6.5 ft): 50 drops from -30°C to 50°C, uncontrolled
RH 2.4 m (8 ft): 20 drops at 25 °C, 55%
RH 3 m (10 ft): MIL-STD-810G, 25°C (77°F), 55% RH 7, 000 1 m ( 3.3 ft) tumbles Environmental sealing IP67 and IP65 Illuminance 0 to 100, 000 lux (9, 290 candlesticks) ESD ±20 kV air discharge, ±8 kV contact discharge Scanning performance Scanning method Image (1280 x 800 pixel array) Motion Tolerance 4500 mm/s (177 in/s)
Scanning Angle Horizontal: 40°, Vertical: 30° Print Contrast Small reflectance difference of 20% Pitch, Pitch, Tilt -360°, 45°, 65° Decoding Capability Read standard 1D, PDF, 2D, Postal, Digimarc, DOT codes and OCR symbols
Drop: 2
m ( 6.5 ft): 50 drops from -30°C to 50°C, uncontrolled
RH 2.4 m (8 ft): 20 drops at 25 °C, 55%
RH 3 m (10 ft): MIL-STD-810G, 25°C (77°F), 55% RH 7, 000 1 m ( 3.3 ft) tumbles Environmental sealing IP67 and IP65 Illuminance 0 to 100, 000 lux (9, 290 candlesticks) ESD ±20 kV air discharge, ±8 kV contact discharge Scanning performance Scanning method Image (1280 x 800 pixel array) Motion Tolerance 4500 mm/s (177 in/s)
Scanning Angle Horizontal: 40°, Vertical: 30° Print Contrast Small reflectance difference of 20% Pitch, Pitch, Tilt -360°, 45°, 65° Decoding Capability Read standard 1D, PDF, 2D, Postal, Digimarc, DOT codes and OCR symbols
