Datalogic QuickScan I QM2131 1D Wireless Handheld Barcode Scanner QM2131-BK-433

Original Brand New Datalogic QM2131 PN: QM2131-BK-433 1D Black Blutooth Barcode Scanner Quickscan Scanner

Description:

Long bar codes are commonly used in a variety of applications including, utilities bills, document processing and packaging. These long codes are a challenge for full area imagers to read due to their narrow field of view and shorter depth of field.

The QuickScan QM2131 imager's extra-wide field of view and extra-long scan line makes reading long bar codes in closer distances much easier. The sharp and highly visible scan line makes the scanner more user-friendly to use, while the enhanced depth of field enables bar codes to be read at an intuitive distance. The stylish design is the signature of the QuickScan series, completing a consistent family appearance.

Featuring Datalogic's STAR 2.0 Cordless System for narrow band 433 Mhz radio communications, the QM2131 linear imager provides secure radio communications with no risk of interference from Wi-Fi infrastructure and very low sensitivity to obstacles like concrete walls, wood or metal shelves.



Features:

- Extra-wide scan angle and extra-long scan line

- Sharp and highly visible scan line

- Enhanced depth of field for general purpose scanning applications

- Datalogic's STAR 2.0 Cordless System with up to 25.0 m / 82.0 ft range

- Secure radio communications, interference-free with low sensitivity to obstacles

- Easy, tool-free, user-replaceable, long-lasting lithium-ion battery

- New battery package allows simultaneous change of charging contacts during battery replacement

- Alternative battery recharging through USB /microUSB cable

- Datalogic's patented 'Green Spot' technology for good-read feedback

- EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI

Specifications

:


Design
International Protection (IP) code
IP42

Product colour
Black

Operational conditions
Operating relative humidity (H-H)
0 - 90 %

Operating temperature (T-T)
0 - 50 °C

Storage temperature (T-T)
-40 - 70 °C

Package dimensions
Depth
18, 7 cm

Gross Weight
0, 63 kg

Height
10, 2 cm

Width
21, 8 cm

Packaging data
Cables included
N

Performance
Buzzer
Y

International Protection (IP) code
IP42

Product colour
Black

Ports & interfaces
Connectivity technology
Wired

Operating frequency
433 MHz

Power
Battery capacity
1400 mAh

Battery technology
Lithium-Ion (Li-Ion)

Input voltage
4.75 - 14 V

Power source type
Battery

Product dimensions
Depth (product, cm)
4, 1 cm

Height (product, cm)
16, 3 cm

Net Weight (Product, kg)
0, 6 kg

Product Width
9, 1 cm

Scanning
Pitch reading angle
-65 - 65 °

Read rate (max)
400 reads/s

Scanner type
1D

Tilt reading angle
-45 - 45 °

Type
Handheld bar code reader

Wavelength
650 nm

Yaw reading angle
-70 - 70 °
