MDR10048 96W DINRail Switching Power Supply

96W DIN-Rail Switching Power Supply 48 Volts 2 Amps Features Universal AC input range
Protections: Short-circuit, Overload, Overvoltage, Over temperature 100% Full load burn-in test Soft-start circuit, limiting AC surge current
Input Voltage: 85-264VAC 47-63Hz, or 120-370VDC
Input Current Full load: 1.3A (115V) / 0.8A (230V)
Size: 3.9 x 2.2" x 3.5"
Weight: 0.9 lbs.
3-year warranty Detailed Specifications: Primary
Output Voltage (VDC): 48
Output Current (A): 2 Maximum
Output Power (W): 96
Family: MDR-100
Input Voltage (VAC): 85 to 264
Input Frequency: 47 to 63
Maximum Input Current (A): 1.3 Output
Connector Type: Screw Terminal
Efficiency (%): 88
Operating Temperature-Min (Cell): -10
Operating Temperature-Max (Cell): 60
Length (inch): 2.17
Width (inch): 3.54
Height (inch): 3.94
Agency Approvals: UL/CUL/TUV/CE
Color: White
Style: DIN".
