Serial RS232 Industrial TCP/UDP Serial RS232 to Ethernet Device Server support Windows System
- YEPLOOK Serial RS232 Industrial TCP/UDP Serial RS232 to Ethernet Device Server support Windows System
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
5V RJ45 to RS232 Industrial TCP/UDP Serial RS232 to Ethernet Device Server support Windows
System NOTE: NO retail package box Please contact us freely for datasheet and manual. Product specification Model number TXB022 Chipset IP210 Port number 1 port 10/100M Auto MDI-MDIX RJ45, 1*com port Standard IEEE 802.3, IEEE 802.3 u, IEEE 802.3 x, IEEE 802.3 az Network media 10Base-T, cat3 or above UTP, 10Base-Tx, cat5 UTP Data rate 10/100M Forwarding rate 10 Mbps / 14, 880 pps, 100 Mbps / 148, 800 pps LED Indicator Link/Act, Power, TX, RX Baud rate 110bps~256000bps Operation modes TCP Server, TCP Client, UDP Dimension 78*72*23mm Power Input DC5V Power Consumption Max 1.5W
Environment Operating Temperature: -10? -55?
Relative Humidity: 10%-90%(non-condensing)
Storage Temperature: -40? -85?
Relative Humidity: 5%-90%(non-condensing) Other function Build load default key
System NOTE: NO retail package box Please contact us freely for datasheet and manual. Product specification Model number TXB022 Chipset IP210 Port number 1 port 10/100M Auto MDI-MDIX RJ45, 1*com port Standard IEEE 802.3, IEEE 802.3 u, IEEE 802.3 x, IEEE 802.3 az Network media 10Base-T, cat3 or above UTP, 10Base-Tx, cat5 UTP Data rate 10/100M Forwarding rate 10 Mbps / 14, 880 pps, 100 Mbps / 148, 800 pps LED Indicator Link/Act, Power, TX, RX Baud rate 110bps~256000bps Operation modes TCP Server, TCP Client, UDP Dimension 78*72*23mm Power Input DC5V Power Consumption Max 1.5W
Environment Operating Temperature: -10? -55?
Relative Humidity: 10%-90%(non-condensing)
Storage Temperature: -40? -85?
Relative Humidity: 5%-90%(non-condensing) Other function Build load default key
