Chip Isolated USB to T-T-L/RS232/RS485 3 in 1 Serial Port Adapter Industrial-Grade T-T-L RS-232 RS-485 Isolation
- New original FT232RL chip, a serial conversion chip with excellent reputation in industrial applications.
- Support Windows/M/Linux 32/64 bit operating system, compatible with the original serial port program without any modification.
- ADI integrated ma~netic isolation chip, good stability, low power consumption and high reliability.
- Communication rate TTL/485: Maximum 921600bps. RS-232: Maximum 460800bps.
- Support 300/600/1200/2400/4800/9600/57600/115200/230400 and other standard baud rates.
+
+
Overview
Specs
Reviews
Any questions? Our AI mode will help you find out quickly.
Try me now
Chip Isolated USB to TTL/RS232/RS485 serial port Adapter Industrial-grade TTL isolation RS-232 isolation RS-485 isolation
Isolated USB to TTL/RS-232/RS-485 converter, without external voltage, adopts industry-renowned FT232RL conversion chip, ADI integrated ma~netic isolation chip, original MORNSUN isolation, integrated static protection, TVS pulse protection, overcurrent Protection and gas discharge lightning protection, CNC aluminum alloy shell, distribution shielded USB cable, automatic transmission and reception switching, speed up to 921600bps, effectively avoiding computer damage, blue screen and crash caused by strong interference, suitable Compatible With various high-demand industrial grades Communication occasions.
Main Feature
new original FT232RL chip, a serial conversion chip with excellent reputation in industrial applications.
Support Windows/M/Linux 32/64 bit operating system, compatible with the original serial port program without any modification.
ADI integrated ma~netic isolation chip, good stability, low power consumption and high reliability.
Communication rate TTL/485: Maximum 921600bps. RS-232: Maximum 460800bps.
Support 300/600/1200/2400/4800/9600/57600/115200/230400 and other standard baud rates.
Support USB to TTL serial port (5V/3.3V), RS-232, RS-485 three functions, one converter takes everything.
Integrated original MORNSUN isolated power supply, no need Compatible With external power supply, USB plug-in can be used
PCB enlarges the isolation partition, the width is more than 3mm, and maintains sufficient creepage distance, and the isolation safety is better.
There is no electrical connection between the USB side and the output side, which fully guarantees that the computer USB will not be damaged due to external shocks or short circuits, and avoid crashes and communication instability caused by interference.
The RS-485 interface integrates four protections against static electricity,
Isolated USB to TTL/RS-232/RS-485 converter, without external voltage, adopts industry-renowned FT232RL conversion chip, ADI integrated ma~netic isolation chip, original MORNSUN isolation, integrated static protection, TVS pulse protection, overcurrent Protection and gas discharge lightning protection, CNC aluminum alloy shell, distribution shielded USB cable, automatic transmission and reception switching, speed up to 921600bps, effectively avoiding computer damage, blue screen and crash caused by strong interference, suitable Compatible With various high-demand industrial grades Communication occasions.
Main Feature
new original FT232RL chip, a serial conversion chip with excellent reputation in industrial applications.
Support Windows/M/Linux 32/64 bit operating system, compatible with the original serial port program without any modification.
ADI integrated ma~netic isolation chip, good stability, low power consumption and high reliability.
Communication rate TTL/485: Maximum 921600bps. RS-232: Maximum 460800bps.
Support 300/600/1200/2400/4800/9600/57600/115200/230400 and other standard baud rates.
Support USB to TTL serial port (5V/3.3V), RS-232, RS-485 three functions, one converter takes everything.
Integrated original MORNSUN isolated power supply, no need Compatible With external power supply, USB plug-in can be used
PCB enlarges the isolation partition, the width is more than 3mm, and maintains sufficient creepage distance, and the isolation safety is better.
There is no electrical connection between the USB side and the output side, which fully guarantees that the computer USB will not be damaged due to external shocks or short circuits, and avoid crashes and communication instability caused by interference.
The RS-485 interface integrates four protections against static electricity,
