Aims Power PICOGLF10W12V120V 1000 Watt Pure Sine Inverter Charger - 12 Volt

The AIMS Power 1000 Watt Pure Sine Low Frequency Inverter with built-in battery charger. This inverter charger is perfect for small-sized industrial applications that depend upon power being available even under heavy load. This heavy-duty inverter charger is ready to go wherever you need it to: campsites, tailgating parties or just at home. Use this product to power your essential household appliances during a power outage emergency. This inverter is also great in a smaller RV or boat.

• 1000 watt low frequency inverter.
• 3000 watt surge for 20 seconds 300% surge capability.
• Battery Priority Selector.
• Terminal Block.
• GFCI outlet.
• Marine Coated and Protected.
• Multi Stage Smart charger 20 Amp.
• remote panel available.
• auto frequency.
• 10msec typical transfer time.
• optional 25W power save mode.
• 7 battery type settings for charger.

• Continuous Output Power: 1000 Watts.
• Surge Rating: 3000 Watts (20 Seconds).
• Output Waveform: Pure Sine/Same as input (Bypass Mode).
• Nominal Efficiency: >88% (Peak).
• Line Mode Efficiency: >95%.
• Output Frequency: 50Hz +/- 0.3H z / 60Hz +/- 0.3H z.
• Typical Transfer Time: 10ms (Max).
• THD: < 10% DC.

• Nominal Input Voltage: 12.0V dc.
• Minimum Start Voltage: 10.0V dc.
• Low Battery Alarm: 10.5V dc- 11.0V dc.
• Low battery
  Trip: 10.0V dc- 10.5V dc.
• High Voltage Alarm: 16.0V dc.
• Low battery
  Voltage Restart: 15.5V dc.
• Idle Consumption: <0.5 amps AC.
• Power Saver Mode Idle Consumption: <1 amps AC.

• Output voltage: Depends on battery Type.
• Charger Rate: 20A.
• Over Charge Protection Shutdown 15.7V.
• Selectable Charge setting based on battery type.
• Adjustable charge current off-20%-100%.
• Four Stage Smart Charger.

• 30 amp automatic transfer switch.
• 10 ms (max).
• Dimension - 15 x 7.05 x 8.59 in.
• Item Weight - 35 lbs.
