AIMS Power PICOGLF30W12V120VR 3000 Watt 12V Pure Sine Inverter Charger

Popular applications for this inverter include: off-grid home or business back up power, providing electricity for a mobile business or mobile office, and running camping equipment. The inverter accepts 12 volts DC, which makes it great for vehicle upfitting as well as boat and RV applications that use a 12 volt battery system. The inverter outputs 120 volts AC. The most popular feature of this unit is the direct connect terminal block, which allows a 300 percent surge capacity for up to 20 seconds. When using the terminal block, this inverter peaks at 9000 watts with the power to run many tools and appliances with a startup surges, such as a refrigerators, freezers, microwaves and blow dryers. 3000 watt low frequency inverter 9000 watt surge for 20 seconds -3x surge capability Battery Priority Selector Terminal Block GFCI - 15 amps Marine Coated and Protected Multi Stage Smart charger 100 Amp Remote panel available Auto gen start Auto frequency 10msec typical transfer time Selectable 25W power save mode (hibernation) 7 battery type settings for charger Specifications Inverter
Output Specifications: Continuous
Output Power: 3000
Watts Surge Rating: 9000 Watts (20 Seconds)
Output Waveform: Pure Sine/Same as input (Bypass Mode)
Nominal Efficiency: >88% (Peak)
Line Mode Efficiency: >95%
Output Frequency: 50Hz +/- 0.3H z / 60Hz +/- 0.3H z
Typical Transfer Time: 10ms (Max) Bypass terminal breaker - 40 amps
THD: < 10% DC Input
Specifications Nominal Input Voltage: 12.0V dc
Minimum Start Voltage: 10.0V dc Low
Battery Alarm: 10.5V dc- 11.0V dc Low battery
Trip: 10.0V dc- 10.5V dc High
Voltage Alarm: 16.0V dc Low battery
Voltage Restart: 15.5V dc Charger breaker - 30 amps
Idle Consumption: 55 Watts Power Saver Mode Idle Consumption: 21.7 Watts Charger
Specifications Output voltage: Depends on battery
Type Charger Rate: 100A Dimensions
Unit Weight: 58 lbs. Unit Size L x W x
H: 16.48 x 8.74 x 7.1 inches
Shipping Weight: 64 lbs. Shipping L x W x H 23.5 x 13.0 x 12.5 inches
