(US Plug)(one TX and one RX)20Km VGA KVM Fiber Extender Over SC Fiber Optical Cable 1080P VGA USB Fiber Extender Transceiver Kit Support USB Keyboard Mouse

Introduction
This extender provides extension of VGA signals long distances over a single Fiber, it supports high resolution up to 1080P, KVM and Audio signal transmission. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security
Features:
1. Transmits VGA video and audio signals up to 20KM over a single Fiber
2. Support video resolution up to 1920*1080P@60Hz
3. Support multiple in and multiple out through optical fiber switch (15*15 matrix function is realized)
4. Support keyboard and mouse
5. Support Audio input/output
6. Support VGA loop output
7. High compatibility, can auto-match source and display device
8. Built-in automatic adjustment system, make the image smooth, clear and stable
9. Built-in ESD protection system
10. Simple to install, plug and play
11. Support 1 TX to many RX, Support Many TX to many RX
pecification
Video
Signal type: VGA Signal
Maximum pixel clock: 380MHz
Maximum data rate: 6.75G bps
Resolution 640x480@60Hz/800x600@60Hz/1024x768@60Hz/1280x720@60Hz/1280x1024@60Hz/1360x768@60Hz/1920x1080@60Hz/1400x1050@60Hz/1440x1050@60Hz/1440x900@60Hz/1920x1200@60Hz/1920x1080@60Hz/1920x1080i@60Hz/1920x1080@50Hz/1920x1080i@50Hz
Audio
Impedance: 75
Interface: 3.5 mm seat
Signal type: Stereo
USB Interface:
PC: USB interface; connect to pc;
K/M: connect USB keyboard and mouse;
Fiber
Interface: SC/FC
Fiber Model: Single mode
wavelength: Single mode 1310nm; 1550nm
bandwidth: 6.25G bps
Transmission distance: Default standard 20KM, MAX up to 80KM
Package
VGA transmitter x1 pcs
VGA receiver x1 pcs
USB Cable x1 pcs
Power adapter x2 pcs
User manual x1 pcs
