Specifications Mfr
Part Number: CASTLE 360
EX WH Color: White
Features: Anti-leak Tech Inside, exclusively safe. 25% more skived fins on the back side of the copper base, the heat absorption area extensively increased. Flow route optimized to reduce operation noise and energy loss. 2 specially tuned TF120 S fans are included (in matching the radiator's properties). Customizable Logo, exciting DIY experience. Ultra large copper base, extensive compatibility (including TR4). 5V Addressable RGB, adjustable through the motherboard, or included the controller.
Socket Type:
Intel: LGA20XX/1151/1150/1155/LGA1366
AMD: TR4/AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
Radiator:
Material: Aluminum
Dimensions: 402×120×27 mm
Pump:
Speed: 2550
RPM±10% Voltage: 12V DC, Current: 0.2A
Connector: 3 pin
Power Consumption: 2.4
W Fan:
Speed: 500~1800 RPM±10%
Air Flow: 64.4 CFM
Air Pressure: 2.33 mmAq
Noise Level: ≤ 32.1 dB (A)
Rated Voltage: 12V DC
Rated Current: 0.15 A
Bearing Type: Hydro
Bearing Connector: 4 pin
Power Consumption: 1.8W
Dimensions: 120.0 x 120.0 x 25.0 mm
Tubing Length: 465mm
Weight: 6.56 LBS
Dimension (inch): 450x252x141mm LED Type:Addressable RGB LED LED Connector:3-pin(+5V-D-G) LED Rated Voltage:5 VDC LED Power Consumption: 2.25 W(PUMP)
