GM400 1U Bronze
Cybenetics Bronze 400W 1U redundant power supply
- 400+400W 24 hours and well-working performance at 45°C fully continuous power output
- 1U redundant form factor with 106mm(W) x 41.5mm(H) x 260mm(D)
- 1+1 redundant configuration
- Hot swappable design
- Convenient pull-out handle bars
- Industry-leading reliability
Product Specifications
| Product No. | SST-GM400-1UB |
|---|---|
| Color | Silver |
| Combined +3.3V & +5V | 150W |
| Input Voltage | 90 ~ 264 Vrms |
| PFC | Active PFC (PF>0.9 at full load) |
| MTBF | 100,000 hours |
| Cooling System | 40mm DC fans |
| Form factor | 1+1 1U redundant |
| Model (safety certification) | SST-1R0400FCBR-A |
|---|---|
| Max. DC Output | 400W |
| Combined +12V | 384W |
| Input Frequency Range | 47Hz ~ 63Hz |
| Efficiency | >=82% & <85% overall efficiency with single modular power supply |
| Operating temperature | 0°C ~ 45°C |
| Noise Level | 52 dBA |
| Dimension | 4.84" (W) x 1.63" (H) x 10.63" (Housing with bracket, without handle) |
