Partaker Fanless Mini PC
Intel Core i3 4005U/i3 5005U/i5 4200U/i5 5250U/i5 5287U/i3 6157U/i3 7167U/i3 8145U Processor
| Model Number |
B1 |
| Color |
Silver |
| Material |
Aluminum |
| CPU |
Intel Core i3-4005U/i3-5005U/i5-4200U/i5-5250U/i3-6157U/i3-7167U Processor |
| Memory |
2* SO-DIMM DDR3L 1333/1600, max. 16GB RAM, CPU i3 8145U for DDR4 RAM |
| Storage |
1* Msata SSD+1* 2.5 Inch HDD |
| Expansion |
1 * MSATA3.0, 6Gb/s; 1 * SATA3.0 , 6Gb/s;1 * WiFi module |
| Mini PCIE |
Full height for MSATA ssd, Half height for wireless network card |
| Audio Cards |
ALC662 |
| Network Card |
RTL8168/8111/8112 PCI-E 10/100/1000 Gigabit NIC |
| WiFi |
With dual antennas, 802.11ac 2.4+5Ghz |
| I/0 Port |
VGA+ HDMI+ 4*USB 3.0+2* USB2.0+ LAN+ Spk+ Mic |
| Power |
DC100-240V AC/50-60Hz, DC 12V/3A/5A |
| Measurement |
197*197*37mm |
| Packing List |
Mini PC+ Power supply+ Power Cord+ Vertical stand+ WiFi antennas |
| Function |
Support diskless boot, Support Restore AC Power Loss, Support dual screen (VGA+HDMI) |
Small But Powerful
Ideal for home entertainment, conference room, education. Integrated port can be used for projector, TV, monitor, printer and more office equipment. Support Wireless WiFi and external storage.
Silent Working
This mini computer adopts fanless and full metal case design. Metal case helps computer to dissipate heat efficiently. The fanless design come trues the electricity bills saving and zero noise.
Rich Interfaces
4xUSB 3.0, 2xUSB 2.0, 1xVGA, 1xHDMI, 1xLAN, 1x Headphone/Microphone Combo.
The Operating System is Windows 10 Pro;
It has been tested well before shipping, if any questions, please contact me, you will get a satisfied solution.
Used as HTPC(Home Theater Personal Computer). Connect HDTV with the HD cable, you can enjoy education online and play internet movies or games.
Personal Computer, Factory, classroom, bank, supermarket, stores.
Widely used in Library, reading room, hotel, training, call center, CCTV company
Model Number: Partaker B1
Color: Silver
Material: Aluminum
CPU: Intel Core i5-4200U Processor (3M Cache, up to 2.60 GHz)
Graphics: Intel HD Graphics 4400
Memory: 2* SO-DIMM DDR3L 1333/1600, LPDDR3 1333/1600, max. 16GB RAM
Storage: 1* Msata SSD+1* 2.5 Inch HDD
Expansion: 1 * MSATA3.0, 6Gb/s; 1 * SATA3.0 , 6Gb/s+ 1 * MSATA SSD, 1 * WiFi module
Mini PCIE: Full height support MSATA solid state drive, Half height support MINI PCIE wireless network card
Audio Cards: 6-channel sound with ALC892 chip
Network Card: RTL8168/8111/8112 PCI-E 10/100/1000 Gigabit NIC
WiFi: With dual antennas, 802.11.b/g/n
Bluetooth: Optional (Default without this function, please do need to leave us message on the order, thank you)
I/0 Port: 1*VGA+ 1*HD-MI+ 4*USB 3.0+2* USB2.0 1*LAN+ Spk+ Mic
Power: DC100-240V AC/50-60Hz, DC 12V/5A
Operating Temperature: 0°C~70°C Centigrade (32°F~140°F)
Storage Temperature: -20°C~80°C Centigrade (-68°F~176°F)
Relative Humidity: 10%~90% (non-condensing)
Mini PC Stand: Yes
Vesa Mount: Optional
Weight: 2.5kgs
Measurement: 197*197*37mm
Consumption: 15W
Motherboard Design: Fanless
Function: 1. Support diskless boot
2. Support power-on (Restore AC Power Loss)
3. Support RAID0
Warranty: 3 years
System Support: Windows 7/8/8.1/10,WES7/8,Linux Ubuntu,Vxworks etc;
System Default Option: Windows 10 pro as the default option;
ATTENTION: Barebone, Single RAM, Single SSD or SSD+HDD without any system.
Linux ubuntu or other OS, Do need to leave us message on the order, thank you.
Special Tip: Barebone System Configuration actually is NO RAM No Storage No System Included, due to system restrict, However we choose 1G DDR3 to be displayed but actually no RAM. Please special attention, NO RAM NO SSD NO HDD for Barebone!! Please read carefully before purchase, we don't accpet return due no RAM no Storage no System.
