POE Injector Ethernet DC12V 48V 15V 1A 12V 2A 24V 1A 24W CCTV Power Supply Adapter Switch for IP camera POE EU Wireless Bridge(24V 1A US Plug)

POE Injector Ethernet DC12V 48V 15V 1A 12V 2A 24V 1A 24W CCTV Power Supply Adapter Switch for IP camera POE EU Wireless Bridge
Features:
This PoE injector is a simple and convenient power supply equipment for PoE or Non PoE devices via only an Ethernet cable, which will save your trouble about power line cabling and save cost, while it does not have auto detection function and directly supply power to the network devices by force as soon as you connect them, please confirm your device carefully when you use it.

Specifications

:
Input: 100-240VAC, 50/60Hz
Output: 48V 0.5A; 24V1A; 15V1A;, 12V 2A
Power feed Pins: +4, 5, - 7, 8
Data in: 1/2, 3/6
Network Interface: 10/100Mbps;
Full Protection: Over current, Over-load, short circuit;
Dimension: 84 (L) *47 (W) * 44.5 (H) mm;
Continuous flow of power
CE FCC approved
Applications:
VoIP Phone
CCTV Security Camera
Satellite Receivers
WiMax Access Points
Wireless Network Access Points
Note:
>> If your camera Lable shows the output 12V/PoE as this picture shows,
then please select this 48V PoE injector, do not select 12V PoE injector.
Because "12V/PoE" means it can offer power to camera via 12VDC port or 48V PoE Ethernet port.
The symbol "/" means "or".
