Laptop External Independent Video Card Graphics Dock Mini PCI-E Version for V8.0 EXP GDC Beast

Specifications

:
Color: Black
Material: PC + PVC
PCI-E: X1 DMI 5GT/s
Input: MINI PCI-E / NGFF M. 2 A/E Key / Expresscard (Optional)
Power: ATX
System: Win7/10
TD SW: 7s/15s
Parts: ATX Power adapter cable
Main Parameters: Support for PCI-E X16, the actual X1 mode (according to different notebook configuration can be upgraded to X4 mode)
Basic Parameters:
Products: Notebook PCI-E expansion device
Product Positioning: Notebook performance upgrade.
Operating System: Windows XP/7/8/ 8.1 /10, MAC OS, Linux etc.
(NOTE: for Win XP, Win8/ 8.1, it's only compatible with the laptop with external screen. )
Input Interface: Mini PCI-E (WLAN\WWAN\DMC), Expresscard (34#/54#), NGFF (Slot A? E? M)
Extended Support: PCI-E X16: DMI 5GT/s (X1)
Compatible Brand: for Asus, GIGABYTE, MSI, GALAXY, Colorful, EVGA, etc
Compatible Model: GTX650\GTX660\GTX670\GTX750\GTX760\GTX770\GTX950\GTX960\GTX970\GTX980\GTX1060\GTX1070\GTX1080
Power Support:
8P Interface: 220W max.
DC Interface: 150W max.
Note: the power limit without ATX cable.
Item Size: 62 * 95 * 212mm / 2.44 * 3.74 * 8.35 in
Item Weight:
108g / 3.81 oz (MINI PCI-E)
107g / 3.77 oz (NGFF M. 2 A/E Key)
123g / 4.34 oz (Expresscard)
Package Size: 18 * 10 * 6cm / 10.8 * 7.3 * 4.4 in
Package Weight:
166g / 5.86 oz (MINI PCI-E)
165g / 5.81 oz (NGFF M. 2 A/E Key)
181g / 6.37 oz (Expresscard)

Package List:
1 * EXP GDCV 8.0 PCI-E Adapter
1 * Mini PCI-E Data Lines
1 * ATX PSU Power Cable
