Product Parameter:
Model.D2E133-CI33-56
Motor:M2E068-CF
Type:Forward Leaning Centrifugal Fan Brand ebm-papst
Nominal voltage:230VAC
Frequency : 50/60Hz
Valid for approval/standard:CE Speed:1700/2100RPM
Power consumption:175/190W
Current draw: 0.77A/0.84A
Capacitor voltage: 400VDB
Weight:3.3kg
Size:133mm
Motor Size:68
Impeller material:Sheet steel, galvanized
Housing material:Sheet steel, galvanized
Degree of protection:IP44
Insulation class:B
Approval:EAC,CCC; Motor bearing:Ball bearing
Package:
Fan*1
