RS485 Serial to Ethernet Converter MQTT TCP to RTU Gateway 1 Port USR-N510

Lightweight MQTT protocolMQTT 3.1 and 3.1.1 both supported,features SSL/TLS security,supports maximum 16 topics publication simultaneously, 16topics subscription simultaneously. Data transmission encryptionSupports SSL/TLS encryption in TCP client, HTTP client and MQTT operation modes Supports two-way certificates authentication. Edge computingN510 actively execute data collection and internal calculate,then transmitsto cloud platform by customized Json format. Edge computing gatewayscan effectively relieve the pressure on the server. Modbus gatewayTransfer between modbus RTU and modbus TCP protocol ,Support modbus multi-host polling,Support up to 128 data points for data collection,support modbus address mapping. Scheme upgrade to provide better experienceMaster chip adopts ST crotex-M7 core, the main frequency is up to 400Mhz, fast processing speed,high stable and reliable performance. High Reliability and StabilityEFT-IEC61000-4-4 Level 3(+-2KV),Built-in hardware watchdog,ESD-IEC61000-4-2 Level 4(air +-15KV contact +-8KV). Redundant Power SupplyWide input voltage DC 5-36V,with reverse polarity protection. Block Diagram. Free Choice of Multiple Working ModesN510 supports TCP ClientTCP ServerUDP ClientUDP ServerHttpd Client etc. operation modes. Synchronizing baud rateChange the baud rate, data bit, check bit and stop bit dynamically via network protocol. PUSR Cloud ManagementEasy to achieve edge computing, pair connection, remote operation and maintenance. Target ApplicationsThe N5X0 series enables instant networking of serial devices and can be deployed in a variety of commercial applications and industrial process automation environments that require serial-to-Ethernet connectivity. These include POS,access control, SCADA systems, environment monitoring, sensor monitoring,device management, remote site management, and more.
