SDI To HDMI Converter HD-SDI 3G-SDI SD-SDI to HDMI SDI Converter Video Adapter

Introduction:

SDI to SDI HDMI Converter allows SDI signals to be shown on two (SDI/ HDMI) display while ensuring high bit rates of 2.970 Gbit/s to give you high resolution signal without any loss. For professionals this means that it is now easier to convert your high def SDI signal with audio to SDI/ HDMI for long distance transmission and display your work on two (SDI/ HDMI) display.



Feature:

100% Brand NEW! High Quality!!

SDI to HDMI Converter converts SD-SDI HD-SDI 3G-SDI to HDMI for driving HDMI monitors.

Auto detect resolution of HD-SDI, SD-SDI and 3G-SDI, Full HDMI supported.

LED Indicator light

HDMI and HDCP compliant.

No need to install drivers, portable, flexible, plug and play.

Specifications

:

Power supply: DC 5V-12V /1A.

Power consumption (Max): 5W.

SDI date rate: 270Mb/s, 1.485G b/s, 2.97G b/s

SDI input resolution: 480i/567i; 720p/50/60; 1080i/50/60; 1080p/24/25/30 SDI

output format: SD-SDI HD-SDI 3G-SDI

Recommended resolutions: 720P@50Hz/60Hz or 1080P@50Hz/60Hz HDMI.

HDMI 1.3 output resolution: 720P@50HZ, 720P@60HZ, 1080i@50HZ, 1080i@60HZ, 1080P@24HZ, 1080P@25HZ, 1080P@30HZ, 1080P@50HZ, 1080P@60HZ.

Operating Temperature: 0'C to +50'C

Operating Humidity: 10% to 85 % RH (no condensation)

Storage Temperature: -10'C to +80'C

Storage Humidity: 5% to 90 % RH (no condensation)

do not support sony and blackmagic device
Package contents:

1 x SDI to SDI HDMI Converter

1 x power adapter

1 x User manual
