Feature: --- No need to install drivers, HDMI to USB 3.0 video capture dongle, easy to carry --- Compatible with Windows, Linux, OS X operating system -- Compatible with many USB 3.0 chipsets (Intel, Renesas, ASMedia, Fresco Logic), speed 300-350MB / s, compatible with USB 2.0 --- The process of video and audio is done by the dongle and does not take up the CPU. --- It can capture a single channel HD HDMI video signal. --- It automatically detects the input video format and automatically adjusts the set output size and frame rate. --- Input and output video signals up to 1080p / 60 Hz. --- It is compatible with UVC video capture and YUV 422 video output.
Product information Host interface: USB
3.0: 300-350MB / s
USB 2.0: 40MB / s
Input interface: DMI interface
HDMI input format: 480i, 480p, 576i, 576p, 720p50, 720p60, 1080i50, 1080i60, 1080P24/ 25/30 / 60;
Frame rate: 25 / 29.97 / 30/50 / 59.94 / 60 fps Audio and video capture standards for UVC and UAC Support for
OS Windows 7 Windows Server 2008 R2 Linux (kernel version 2.6. 38 and higher) OS X ( 10.8 and above)
Software compatible: Windows Media Encoder (Windows) Adobe Flash Media Live Encoder (Windows, OS X) Real Producer Plus (Windows) VLC (Windows, OS X, Linux) Quick
Time Broadcaster (OS X) Quick
Time Player (OS X) Wirecast (Windows, OS X) Potplayer (Windows), etc.
Interface compatibility: Direct
Show (Windows), Direct
Sound (Windows), V4L2 (Linux), ALSA (Linux) OS X (Quick
Time) Package 1*HDMI to USB 3.0 video capture 1*USB power cord 1*USB 3.0 cable 1*HDMI cable 1* User Manual
