4U all-in-one machine / industrial all-in-one machine / industrial control chassis / 19-inch standard rack-mounted industrial chassis /4U workstation empty chassis
- Chassis size: 550mm deep × 428mm wide × 177mm high, 19 "standard rack-mounted industrial chassis.
- Main material: aluminum alloy; environmental protection, fingerprint resistance 1.2mm / SGCC.
- Surface treatment: The outer surface is black, and the internal accessories are not sprayed.
- Hard disk position: 2 front hot-plug 3.5 "compatible 2.5" hard disk positions, built-in 1 3.5 "hard disk position or 2 2.5" hard disk positions
- Optical drive position: 1 ultra-thin notebook optical drive position.
- Hard disk backplane: One 2-disk SATA backplane.
- Fan position: two 8025S fans, large 4P interface, two 6 cm fan positions on the rear window.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Applicable motherboard: motherboards under 12 "* 13"
External interface: 2.0USB * 2
System control: (switch, light) power switch, restart switch, power indicator, hard disk indicator
Applicable power supply: Standard PS2 series power supply
Internal accessories: one 500? long, 15P two-end male VGA extension cable, 2 screw bags, 1 accessory box
Packing: Four corners set corner pearl cotton + double carton
Packing size: 700 * 580 * 305mm
Screen / Keyboard: 8.9 "LCD screen Touch (87F) keyboard + mouse USB connector
Screen resolution: 1024 * 600
Components Specification
Dimensions(WxDxH) 428mm x 550mm x 177mm.
Materials Quality fine 1.2mm SGCC steel.
Display Support 8.9" LCD display.
Color Black.
Drivers bay 2 x 3.5" HDD drive bays, 1 x 5.25" CD-ROM bay.
Cooling Fan 2 x 80mm fans on front,2*60mm fans on the rear panel.
PSU form factor Standard PS2 power supply.
M/B form factor Support MAX 12" x 13" motherboard.
Epansion space 7 PCI expansion slots.
Input device Slim notebook keyboard and touchable mouse pad.
Connector Two front accessible USB2.0 ports.
System Control
Power switch, Reset switch, Power LED, HDD LED.
Applicarion
Indusrrial control, IOT, machine automation, communication etc.
Product Features:
1.Conformed with EMC design standard to prevent from electromagnetic interference.
2.Support motherboard size up to MAX 12" x 13", and 2 x 3.5" HDD drive bays, 1 x 5.25" CD-ROM bay, Support 8.9" LCD display, Standard PS2 power supply.
3.The chassis has good ventilation system 2 x 80mm fans on front, 2*60mm fans on the rear panel to make sure the system work steadily.
External interface: 2.0USB * 2
System control: (switch, light) power switch, restart switch, power indicator, hard disk indicator
Applicable power supply: Standard PS2 series power supply
Internal accessories: one 500? long, 15P two-end male VGA extension cable, 2 screw bags, 1 accessory box
Packing: Four corners set corner pearl cotton + double carton
Packing size: 700 * 580 * 305mm
Screen / Keyboard: 8.9 "LCD screen Touch (87F) keyboard + mouse USB connector
Screen resolution: 1024 * 600
Components Specification
Dimensions(WxDxH) 428mm x 550mm x 177mm.
Materials Quality fine 1.2mm SGCC steel.
Display Support 8.9" LCD display.
Color Black.
Drivers bay 2 x 3.5" HDD drive bays, 1 x 5.25" CD-ROM bay.
Cooling Fan 2 x 80mm fans on front,2*60mm fans on the rear panel.
PSU form factor Standard PS2 power supply.
M/B form factor Support MAX 12" x 13" motherboard.
Epansion space 7 PCI expansion slots.
Input device Slim notebook keyboard and touchable mouse pad.
Connector Two front accessible USB2.0 ports.
System Control
Power switch, Reset switch, Power LED, HDD LED.
Applicarion
Indusrrial control, IOT, machine automation, communication etc.
Product Features:
1.Conformed with EMC design standard to prevent from electromagnetic interference.
2.Support motherboard size up to MAX 12" x 13", and 2 x 3.5" HDD drive bays, 1 x 5.25" CD-ROM bay, Support 8.9" LCD display, Standard PS2 power supply.
3.The chassis has good ventilation system 2 x 80mm fans on front, 2*60mm fans on the rear panel to make sure the system work steadily.
