Suitable for motherboards: Support E-ATX motherboards and various motherboards with sizes of 12"*13" and below
System control: Power SW*1, Reset*1, PowerLED*1, HDD LED*1, NID LED*2, USB 2.0 *1
Power supply: standard 2U power supply and redundant power supply
Expansion slots: 7 half-height PCI/PCIE expansion slots
Slide: Three-section ball slide or simple slide
Application areas: cloud storage, cloud computing, big data, security monitoring and other fields
Components Specification
Dimensions (mm) 437.5 mm x 650mm x 265mm, standard 19" rackmount chassis.
Materials 1.0 mm SGCC Zinc-Coated Steel.
Backplane 6Gb/s Expander backplane, with temperature control chipset. / 12Gb/s Expander backplane, with temperature control chipset.
Drivers bay 60X 3.5" hot-swap Sata/Sas drive bays, 2X 2.5" drive bays.
Cooling Fan 6X12038 hot-swap fans.
PSU form factor CRPS power supply.
M/B form factor MAX supports to 13.68" x13"(EE-ATX) motherboard.
Epansion space 7 half-height PCI/PCIE expansion slots.
Connector Two front accessible USB 2.0 ports(Optional USB 3.0 ).
System Control
Power LED*1, Reset*1, Power SW*1, HDD LED*1, NIC LED*2, UID LED*1, UID SW*1, OH/FAN Fail LED*1, Power Fail LED*1.
Applicarion
Cloud storage, cloud computing, big data, security monitoring, LOTetc.
Product Features:
1. Conformed with EMC design standard to prevent from electromagnetic interference.
2. Support motherboard size up to 13.68" x13", and 60* 3.5"HDD bays, CRPS power supply.
3. The chassis has good ventilation system 6X12038 hot-swap fans. to make sure the system work steadily.
