MW Mean Well SDR-480-48 48V 10A DIN Rail Power Supplies

High efficiency up to 94%
Built-in active PFC function (SDR-120/240/480/960)
Can be installed on DIN rail TS-35 / 7.5 or 15
Built-in DC OK relay contact
3 years warranty

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Features
High efficiency up to 94%
Universal AC input / Full range (SDR-75/120/240/480) AC input 180~264VAC only (SDR-960)
Built-in active PFC function (SDR-120/240/480/960)
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Can be installed on DIN rail TS-35 / 7.5 or 15
UL508(industrial control equipment) approved
EN61000-6-2(EN50082-2) industrial immunity level
Built-in DC OK relay contact (except for SDR-75)
150% peak load capability (SDR-75/120/240/480)
130% peak load capability (SDR-960)
Current sharing up to 3840W (7+1) for SDR-480P
Current sharing up to 3840W (3+1) for SDR-960
Comply with GL (SDR-120/240/480)
Comply with SEMI F47 (SDR-75/120/240/480)
3 years warranty
