KINGDEL Powerful Mini PC i7-1255U Processor 10Cores Max 4.70GHz 32GB DDR5 RAM 2TB NVMe SSD Fanless Desktop Computer with 8K Triple Display 2HD/DP/8xCOM/GPIO/3xLAN/8xUSB
- CPU ProcessorMini Fanless PC comes with Core i7-1255U Processor (12th Generation Core i7 Processors), 10 Cores, 12 Threads, 4.70GHz Max Turbo Frequency, 3.50 GHz Efficient-core Max Turbo Frequency, 12MB Smart Cache.
- StorageThe Fanless Mini PC pre-installed 32GB DDR5 4800MHz RAM, 2TB M.2 NVMe 2280 SSD.
- Processor GraphicsThe Powerful Industrial PC is equipped with Iris Xe Graphics eligible, Max Resolution(HD)4096x2304@60Hz, Max Resolution(DP)7680x4320@60Hz, 1.25GHz Graphics Max Dynamic Frequency. Support 8K.
- Rich I/O InterfacesMini computer includes 4xUSB3.0, 4xUSB2.0, 1xDP, 2xHD, 3xi226 2.5G LAN, 8xRS232 COM, 1x Audio input/output, 1xGPIO, 1xKB/MS, 1xDC IN, 1xSW.
- Fanless Cooling DesignThe Faster Mini Desktop Computer features a fanless design, perfect for quiet and dust-free working scenarios and equipped with a powerful metal body that acts as a heat sink, ensuring silent operation.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
CPU Processor12th Generation i7-1255U, 10 Cores, 12 Threads, 4.70GH z Max Turbo Frequency, 3.50 GHz Efficient-core Max Turbo Frequency, 12MB Smart Cache. GPU
Iris Xe Graphics eligible, Max Resolution (HD) 4096x2304@60Hz, Max Resolution (DP) 7680x4320@60Hz, 1.25GH z Graphics Max Dynamic Frequency. Support 8K. RAM2*DDR5 4800MHz RAM Slots, Support 64GB Max. SSD2*M. 2 2280 NVME SSD slots support PCIE 4.0 x4, 1* 2.5 inches
HDD
Display4K: 2*HD(4096x2304@60Hz)
& 8K: 1*DP(7680x4320@60Hz)Network CardOnboard 3*i226V 2.5G LAN; 1*MINI PCIE interface 4G module, onboard SIM card slot. Sound CardUSB sound card chip and HD simulates 6-channel sound effectUSB Interface8*USB, including 4*USB 3.0 and 4*USB 2.0COM Port8*COM port, of which COM1&COM2 support RS232 RS422 RS485 soft handoffGPIO Port8-bit GPIO meets more industrial equipment needsOther FeatureSupport Restore AC Power Loss, Power-On by Alarm, Wake On Lan and PXE
Power SupplyAC100-240V, 50-60Hz;
Output: DC 19VTemperatureOperating
Temperature: -10°C~60°C;
Storage Temperature: -20°C~80°C;
Relative Humidity: 10%~90% (non-condensing)Size255mmx155mmx80mmKINDLY BE ADVISED
There are 2 types of
DP cables available: "Active" and "Passive". The DP port from the computer works with "Active" type DP cable, if yours is "Passive", it won't display. KINGDEL Powerful Desktop Computer i7-1255U with 8K Triple Display 2HD/DP/8xCOM KINGDEL NC9000 i7-1255U Fanless Mini PC
Iris Xe Graphics eligible, Max Resolution (HD) 4096x2304@60Hz, Max Resolution (DP) 7680x4320@60Hz, 1.25GH z Graphics Max Dynamic Frequency. Support 8K. RAM2*DDR5 4800MHz RAM Slots, Support 64GB Max. SSD2*M. 2 2280 NVME SSD slots support PCIE 4.0 x4, 1* 2.5 inches
HDD
Display4K: 2*HD(4096x2304@60Hz)
& 8K: 1*DP(7680x4320@60Hz)Network CardOnboard 3*i226V 2.5G LAN; 1*MINI PCIE interface 4G module, onboard SIM card slot. Sound CardUSB sound card chip and HD simulates 6-channel sound effectUSB Interface8*USB, including 4*USB 3.0 and 4*USB 2.0COM Port8*COM port, of which COM1&COM2 support RS232 RS422 RS485 soft handoffGPIO Port8-bit GPIO meets more industrial equipment needsOther FeatureSupport Restore AC Power Loss, Power-On by Alarm, Wake On Lan and PXE
Power SupplyAC100-240V, 50-60Hz;
Output: DC 19VTemperatureOperating
Temperature: -10°C~60°C;
Storage Temperature: -20°C~80°C;
Relative Humidity: 10%~90% (non-condensing)Size255mmx155mmx80mmKINDLY BE ADVISED
There are 2 types of
DP cables available: "Active" and "Passive". The DP port from the computer works with "Active" type DP cable, if yours is "Passive", it won't display. KINGDEL Powerful Desktop Computer i7-1255U with 8K Triple Display 2HD/DP/8xCOM KINGDEL NC9000 i7-1255U Fanless Mini PC
