SJRC Industrial Mini PC Fanless with Core i5-1335U, DDR5, 2.5GbE LAN, 6 RS-232/485 COM, 9-36V DC, HD+VGA, Support Linux/Win/Opnsense, 6 USB, Barebone NO RAM NO SSD NO OS
- Expandable DDR5 & Storage: Comes with 2x DDR5 SODIMM slots (up to 64GB) for higher speed vs DDR4. Storage options include 1x M.2 NVMe 2280, 1x mSATA, and 1x 2.5" SATA bay. Also supports PXE boot for diskless systems and a watchdog timer for system stability.
- Industrial-Grade CPU Performance: Running on In-tel 13th Gen Core i5-1335U, this passively cooled system offers 10 cores (2P+8E), 12 threads, turbo up to 4.6GHz, 12MB cache, and 15W TDP, Delivered without OS, Built for continuous operations, automation, and low-power multitasking at the edge.
- Robust Connectivity & Expandability: Offers 6x RS-232 (4 w/ RS485/RS442), 2x 2.5GbE LAN (i225V), USB 3.0 x4, USB 2.0 x2, 14-pin GPIO, HD+VGA dual video, and modular with 4G SIM support, Tailored for industrial setups like PLCs, CNCs, and IoT edge systems.
- Compact & Versatile Installation: Small yet powerful, this 4.85 lb system (9.8"x5.9"x3.4") installs easily on walls or desktops with the included bracket, Fits neatly into tight enclosure
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
"Industrial Fanless Mini PC with In-tel Core i5-1335U
Please note: This is a barebone only. A system memory, a storage drive and an operating system are needed to complete this item
Why Choose This Industrial PC?
Reliability: Fanless design reduces failure risks in dusty or high-vibration settings.
Scalability: Expand with 4G modules, additional storage, or custom I/O.
Easy Integration: Pre-configured for Win/Linux; UEFI BIOS for quick setup.
Technical Specifications:
System: No OS
CPU: 13th Gen Core i5-1335U (10C/12T, 4.6GHz).
Memory: 2x DDR5 SODIMM (64GB Max). Note: It will take 5-10 minutes for the device to detect the RAM for the first time. Please be patient.
I/O: 6x RS-232 COM ports (4 support RS485/RS442), 14-pin GPIO, 4x USB 3.0, 2x USB 2.0, HDMl 4K, VGA, PS/2, audio jacks.
Storage: M.2 NVMe 2280 + mSATA + 2.5"" SATA.
Networking: 2x i225V 2.5GbE (2.4G/5G connection).
Power: 9-36V DC input (3-pin Phoenix terminal).
Dimensions: 9.8"" x 5.9"" x 3.4"" (249x150x86mm).
Weight: 4.85 lbs (2.2kg).
Operating Temperature: -20°C to +60°C.
Storage Temperature: -30°C to +70°C.
Humidity: 10%~90% non-condensing.
Expansion: 1x full-height Mini-PCIe (Support 3G/4G moduleT) with SIM slot, 1x half-height Mini-PCIe .
Package Includes:
1x Mini PC, 1x power adapter, 1x bracket, 2x antennas, 1x SATA cable.
"
Please note: This is a barebone only. A system memory, a storage drive and an operating system are needed to complete this item
Why Choose This Industrial PC?
Reliability: Fanless design reduces failure risks in dusty or high-vibration settings.
Scalability: Expand with 4G modules, additional storage, or custom I/O.
Easy Integration: Pre-configured for Win/Linux; UEFI BIOS for quick setup.
Technical Specifications:
System: No OS
CPU: 13th Gen Core i5-1335U (10C/12T, 4.6GHz).
Memory: 2x DDR5 SODIMM (64GB Max). Note: It will take 5-10 minutes for the device to detect the RAM for the first time. Please be patient.
I/O: 6x RS-232 COM ports (4 support RS485/RS442), 14-pin GPIO, 4x USB 3.0, 2x USB 2.0, HDMl 4K, VGA, PS/2, audio jacks.
Storage: M.2 NVMe 2280 + mSATA + 2.5"" SATA.
Networking: 2x i225V 2.5GbE (2.4G/5G connection).
Power: 9-36V DC input (3-pin Phoenix terminal).
Dimensions: 9.8"" x 5.9"" x 3.4"" (249x150x86mm).
Weight: 4.85 lbs (2.2kg).
Operating Temperature: -20°C to +60°C.
Storage Temperature: -30°C to +70°C.
Humidity: 10%~90% non-condensing.
Expansion: 1x full-height Mini-PCIe (Support 3G/4G moduleT) with SIM slot, 1x half-height Mini-PCIe .
Package Includes:
1x Mini PC, 1x power adapter, 1x bracket, 2x antennas, 1x SATA cable.
"
